Chiaravalli Adjustable V-Belt Pulley PRB 2 Grooves — product photo
Chiaravalli

Adjustable V-Belt Pulley PRB 2 Grooves

Variable-pitch V-belt pulley PRB, 2 grooves, for taper bushes. The effective pitch diameter dr adjusts between the min and max values listed per belt section (Z / A / B and SPZ / SPA / SPB); executions 1 and 2 as drawn.

Grub screws DIN 916 / UNI 5929 as listed per pulley.

Product Configuration

Select a row to add it to your quote

Code TypeExec.BushØ ell1b1 minb1 maxdr min–maxd2d3RBelt sections Weight CAD
90001082 PRB2-108 3 1215 108 mm 73 mm 58 mm 10 mm 17.5 mm 68–92 / 70–100 / 75–93 / 76–102 mm 57 mm M72x2 34.5 mm Z 10x6, A 13x8, SPZ, SPA 2.4 kg
90001202 PRB2-120 3 1215 120 mm 73 mm 58 mm 10 mm 17.5 mm 80–104 / 82–112 / 87–105 / 88–114 mm 57 mm M72x2 34.5 mm Z 10x6, A 13x8, SPZ, SPA 2.65 kg
90001382 PRB2-138 3 1615 138 mm 73 mm 58 mm 10 mm 17.5 mm 98–122 / 100–130 / 105–123 / 106–132 mm 69 mm M85x2 34.5 mm Z 10x6, A 13x8, SPZ, SPA 3.6 kg
90001602 PRB2-160 3 1615 160 mm 87 mm 68 mm 13 mm 22.5 mm 108–138 / 112–150 / 114–140 / 117–153 mm 69 mm M85x2 48.5 mm A 13x8, B 17x11, SPA, SPB 5.6 kg
90001802 PRB2-180 3 2012 180 mm 87 mm 68 mm 13 mm 22.5 mm 128–158 / 132–170 / 134–160 / 137–173 mm 87 mm M110x2 54 mm A 13x8, B 17x11, SPA, SPB 7.15 kg
90002002 PRB2-200 3 2012 200 mm 87 mm 68 mm 13 mm 22.5 mm 149–177 / 152–190 / 155–179 / 159–193 mm 87 mm M110x2 54 mm A 13x8, B 17x11, SPA, SPB 8.92 kg

Product Information

Material
Cast iron G20 UNI 5007

Need help specifying this product?

Our technical team can help you specify the right component. Add it to your quote basket above, or contact us directly.
