Chiaravalli CHT® Chain Tensioner CHT-EGE Front-Mounted — product photo
Chiaravalli

CHT® Chain Tensioner CHT-EGE Front-Mounted

Chain Tensioner CHT-EGE Front-Mounted — Chiaravalli CHT® tensioner (catalogue page 37).

  • E with high molecular weight UHMW polyethylene chain tensioner with a bushing kit that allows free of the slider. elastic elements. available with GA and GO shoes, sizes on page 38. with assembly bolt. MOUNTED VERSION AVAILABLE REQUEST available on www.chiaravalli.com quantity and prices on B2B Chiaravalli

Product Configuration

Select a row to add it to your quote

Code TypeChainChain pitchNewton A2Newton A1ABCDHILM Weight
94070901MF EGE 1 - 3/8 Single 3/8 x 7/32” 0-110 0-110 20 mm 20 mm — 68 +2/-0 mm 45 mm 45 mm — M8 0.3 kg
94070902MF EGE 1 - 3/8 Double 3/8 x 7/32” 0-110 0-110 20 mm 20 mm — 68 +2/-0 mm 45 mm 45 mm — M8 0.3 kg
94070903MF EGE 2 - 3/8 Triple 3/8 x 7/32” 0-160 0-160 — — 25 mm 68 +2/-0 mm — — 45 mm M10 0.5 kg
94071201MF EGE 2 - 1/2 Single 1/2” x 5/16” 0-160 0-160 20 mm 20 mm — 68 +2/-0 mm 55 mm 55 mm — M10 0.5 kg
94071202MF EGE 2 - 1/2 Double 1/2” x 5/16” 0-160 0-160 20 mm 20 mm — 68 +2/-0 mm 55 mm 55 mm — M10 0.5 kg
94071211MF EGE 3 - 1/2 Single 1/2” x 5/16” 0-410 0-410 20 mm 20 mm 35 mm 68 +2/-0 mm 55 mm 60 mm 70 mm M10 0.75 kg
94071213MF EGE 3 - 1/2 Triple 1/2” x 5/16” 0-410 0-410 20 mm 20 mm 35 mm 68 +2/-0 mm 55 mm 60 mm 70 mm M10 0.75 kg
94071212MF EGE 3 - 1/2 Double 1/2” x 5/16” 0-410 0-410 20 mm 20 mm 35 mm 68 +2/-0 mm 55 mm 60 mm 70 mm M10 0.75 kg
94071501MF EGE 3 - 5/8 Single 5/8” x 3/8” 0-410 0-410 20 mm 25 mm — 88 +2/-0 mm 55 mm 70 mm — M10 0.78 kg
94071502MF EGE 3 - 5/8 Double 5/8” x 3/8” 0-410 0-410 20 mm 25 mm — 88 +2/-0 mm 55 mm 70 mm — M10 0.78 kg
94071901MF EGE 3 - 3/4 Single 3/4” x 7/16” 0-410 0-410 20 mm 30 mm — 88 +2/-0 mm 60 mm 70 mm — M10 0.8 kg
94071902MF EGE 3 - 3/4 Double 3/4” x 7/16” 0-410 0-410 20 mm 30 mm — 88 +2/-0 mm 60 mm 70 mm — M10 0.8 kg
94071503MF EGE 4 - 5/8 Triple 5/8” x 3/8” 0-1000 0-1000 — — 40 mm 88 +2/-0 mm — — 100 mm M12 2.1 kg
94071911MF EGE 4 - 3/4 Single 3/4” x 7/16” 0-1000 0-1000 20 mm 30 mm 49 mm 88 +2/-0 mm 80 mm 80 mm 100 mm M12 2.1 kg
94071913MF EGE 4 - 3/4 Triple 3/4” x 7/16” 0-1000 0-1000 20 mm 30 mm 49 mm 88 +2/-0 mm 80 mm 80 mm 100 mm M12 2.1 kg
94071912MF EGE 4 - 3/4 Double 3/4” x 7/16” 0-1000 0-1000 20 mm 30 mm 49 mm 88 +2/-0 mm 80 mm 80 mm 100 mm M12 2.1 kg
94072501MF EGE 4 -1 Single 1” x 17 mm 0-1000 0-1000 20 mm 45 mm 78 mm 108 +2/-0 mm 80 mm 90 mm 100 mm M12 2.2 kg
94072503MF EGE 4 -1 Triple 1” x 17 mm 0-1000 0-1000 20 mm 45 mm 78 mm 108 +2/-0 mm 80 mm 90 mm 100 mm M12 2.2 kg
94072502MF EGE 4 -1 Double 1” x 17 mm 0-1000 0-1000 20 mm 45 mm 78 mm 108 +2/-0 mm 80 mm 90 mm 100 mm M12 2.2 kg
94072513MF EGE 5 -1 Triple 1” x 17 mm 0-1850 0-1850 — 45 mm 78 mm 108 +2/-0 mm — 100 mm 120 mm M20 4.0 kg
94072512MF EGE 5 -1 Double 1” x 17 mm 0-1850 0-1850 — 45 mm 78 mm 108 +2/-0 mm — 100 mm 120 mm M20 4.0 kg
94073101MF EGE 5 -1 1/4 Single 1”1/4 x 3/4” 0-1850 0-1850 20 mm 54 mm 90 mm 108 +2/-0 mm 100 mm 120 mm 130 mm M20 4.2 kg
94073103MF EGE 5 -1 1/4 Triple 1”1/4 x 3/4” 0-1850 0-1850 20 mm 54 mm 90 mm 108 +2/-0 mm 100 mm 120 mm 130 mm M20 4.2 kg
94073102MF EGE 5 -1 1/4 Double 1”1/4 x 3/4” 0-1850 0-1850 20 mm 54 mm 90 mm 108 +2/-0 mm 100 mm 120 mm 130 mm M20 4.2 kg
94073801MF EGE 5 -1 1/2 Single 1”1/2 x 1” 0-1850 0-1850 20 mm 71 mm 119 mm 108 -0 mm 100 mm 120 mm 130 mm M20 4.2 kg
94073803MF EGE 5 -1 1/2 Triple 1”1/2 x 1” 0-1850 0-1850 20 mm 71 mm 119 mm 108 -0 mm 100 mm 120 mm 130 mm M20 4.2 kg
94073802MF EGE 5 -1 1/2 Double 1”1/2 x 1” 0-1850 0-1850 20 mm 71 mm 119 mm 108 -0 mm 100 mm 120 mm 130 mm M20 4.2 kg
