CHT® Linear Tensioner CHT-ASR SS

Linear Tensioner CHT-ASR SS — Chiaravalli CHT® tensioner (catalogue page 58).

  • Tensioner AS INOX with head for accessory fastening
  • Self-lubricating Stainless Steel bushes
  • Force expressed in N is obtained through “pressure” tests performed in the laboratory
  • With loop cover plate
  • Material: AISI 304 Stainless Steel, available in AISI 316 upon request
  • Mirror finish

Product Configuration

Select a row to add it to your quote

Code TypeChainNewtonAB with metal sheetB without metal sheetC with metal sheetC without metal sheetD minD maxLM with metal sheetM without metal sheetNOPQ min singleQ max singleS min doubleS max double CAD
94ASR138STSS ASR1-3/8” Z15 SS Single 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 20.73 mm 26 mm 25.39 mm 25.39 mm
94ASR138DTSS ASR1-3/8” Z15 SS Double 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 20.73 mm 26 mm 25.39 mm 25.39 mm
94ASR112STSS ASR1-1/2” Z15 SS Single 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 20.98 mm 24.76 mm 27.88 mm 27.88 mm
94ASR112DTSS ASR1-1/2” Z15 SS Double 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 20.98 mm 24.76 mm 27.88 mm 27.88 mm
94ASR158STSS ASR1-5/8” Z15 SS Single 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 22.52 mm 44.86 mm 29.65 mm 36.2 mm
94ASR158DTSS ASR1-5/8” Z15 SS Double 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 22.52 mm 44.86 mm 29.65 mm 36.2 mm
94ASR258STSS ASR2-5/8” Z15 SS Single 460 65 mm 32 mm 30 mm 89 mm 87 mm 130 mm 164 mm 25 mm 8 mm 6 mm 60.5 mm M12 x 55 67 mm 19.18 mm 39.88 mm 30.52 mm 31.9 mm
94ASR258DTSS ASR2-5/8” Z15 SS Double 460 65 mm 32 mm 30 mm 89 mm 87 mm 130 mm 164 mm 25 mm 8 mm 6 mm 60.5 mm M12 x 55 67 mm 19.18 mm 39.88 mm 30.52 mm 31.9 mm
94ASR234STSS ASR2-3/4” Z15 SS Single 460 65 mm 32 mm 30 mm 89 mm 87 mm 130 mm 164 mm 25 mm 8 mm 6 mm 60.5 mm M12 x 55 67 mm 22.85 mm 39.9 mm 30.23 mm 30.23 mm
94ASR234DTSS ASR2-3/4” Z15 SS Double 460 65 mm 32 mm 30 mm 89 mm 87 mm 130 mm 164 mm 25 mm 8 mm 6 mm 60.5 mm M12 x 55 67 mm 22.85 mm 39.9 mm 30.23 mm 30.23 mm
94ASR31STSS ASR3-1” Z12 SS Single 690 80 mm 37 mm 106 mm 106 mm 104 mm 161.7 mm 197.7 mm 30 mm 9 mm 7 mm 73 mm M14 x 60 80 mm 28.55 mm 53.55 mm 38.08 mm 38.08 mm
94ASR31DTSS ASR3-1” Z12 SS Double 690 80 mm 37 mm 106 mm 106 mm 104 mm 161.7 mm 197.7 mm 30 mm 9 mm 7 mm 73 mm M14 x 60 80 mm 28.55 mm 53.55 mm 38.08 mm 38.08 mm

Product Information

Material
AISI 304 stainless steel
