Chiaravalli CHT® Rotating Belt Tensioner CHT-ERU — product photo
Chiaravalli

CHT® Rotating Belt Tensioner CHT-ERU

Rotating Belt Tensioner CHT-ERU — Chiaravalli CHT® tensioner (catalogue page 34).

  • Tensioner E with belt tensioner roller RU (simple, double or triple)
  • Rubber elastic elements
  • Supplied with assembly bolt. FRONT MOUNTED VERSION AVAILABLE UPON REQUEST

Product Configuration

Select a row to add it to your quote

Code TypeRollerNewton A2Newton A1A ØBCDM Weight CAD
94073521 ERU 1 - 3035 Steel 0-90 0-110 30 mm 35 mm 51 mm 43 mm M8 0.33 kg
94073511 ERU 1 - 3035 Polyamide 0-90 0-110 30 mm 35 mm 51 mm 43 mm M8 0.25 kg
94073501 ERU 1 - 3035 Aluminium 0-90 0-110 30 mm 35 mm 51 mm 43 mm M8 0.27 kg
94074522 ERU 2 - 4045 Steel 0-130 0-160 40 mm 45 mm 67 mm 56 mm M10 0.68 kg
94074512 ERU 2 - 4045 Polyamide 0-130 0-160 40 mm 45 mm 67 mm 56 mm M10 0.53 kg
94074502 ERU 2 - 4045 Aluminium 0-130 0-160 40 mm 45 mm 67 mm 56 mm M10 0.57 kg
94075022 ERU 2 - 5050 Steel 0-130 0-160 50 mm 50 mm 69 mm 58 mm M12 0.95 kg
94075012 ERU 2 - 5050 Polyamide 0-130 0-160 50 mm 50 mm 69 mm 58 mm M12 0.58 kg
94075002 ERU 2 - 5050 Aluminium 0-130 0-160 50 mm 50 mm 69 mm 58 mm M12 0.64 kg
94074523 ERU 3 - 4045 Steel 0-330 0-410 40 mm 45 mm 67 mm 57 mm M10 0.93 kg
94074513 ERU 3 - 4045 Polyamide 0-330 0-410 40 mm 45 mm 67 mm 57 mm M10 0.78 kg
94074503 ERU 3 - 4045 Aluminium 0-330 0-410 40 mm 45 mm 67 mm 57 mm M10 0.82 kg
94075023 ERU 3 - 5050 Steel 0-330 0-410 50 mm 50 mm 69 mm 59 mm M12 1.2 kg
94075013 ERU 3 - 5050 Polyamide 0-330 0-410 50 mm 50 mm 69 mm 59 mm M12 0.83 kg
94075003 ERU 3 - 5050 Aluminium 0-330 0-410 50 mm 50 mm 69 mm 59 mm M12 0.89 kg
94076024 ERU 4 - 6060 Steel 0-800 0-1000 60 mm 60 mm 89 mm 76 mm M12 2.98 kg
94076014 ERU 4 - 6060 Polyamide 0-800 0-1000 60 mm 60 mm 89 mm 76 mm M12 2.24 kg
94076004 ERU 4 - 6060 Aluminium 0-800 0-1000 60 mm 60 mm 89 mm 76 mm M12 2.35 kg
94078025 ERU 5 - 8090 Steel 0-1500 0-1850 80 mm 90 mm 127 mm 109 mm M20 6.5 kg
94078015 ERU 5 - 8090 Polyamide 0-1500 0-1850 80 mm 90 mm 127 mm 109 mm M20 4.4 kg
94078005 ERU 5 - 8090 Aluminium 0-1500 0-1850 80 mm 90 mm 127 mm 109 mm M20 4.9 kg
94079013526 ERU 6 - 90135 Steel 0-2500 0-3100 90 mm 135 mm 169 mm 154 mm M20 9.0 kg
94079016 ERU 6 - 90135 Polyamide 0-2500 0-3100 90 mm 135 mm 169 mm 154 mm M20 8.2 kg
94079013506 ERU 6 - 90135 Aluminium 0-2500 0-3100 90 mm 135 mm 169 mm 154 mm M20 7.5 kg
94079013517 ERU 7 - 90135 Steel 0-3800 0-4800 90 mm 135 mm 169 mm 154 mm M20 12.0 kg
94079013527 ERU 7 - 90135 Polyamide 0-3800 0-4800 90 mm 135 mm 169 mm 154 mm M20 10.7 kg
94079013507 ERU 7 - 90135 Aluminium 0-3800 0-4800 90 mm 135 mm 169 mm 154 mm M20 11.0 kg
View supplier page (CAD)

Need help specifying this product?

Our technical team can help you specify the right component. Add it to your quote basket above, or contact us directly.

Contact Us
