Chiaravalli CHT® Rotating Belt Tensioner CHT-ERU Front-Mounted — product photo
Chiaravalli

CHT® Rotating Belt Tensioner CHT-ERU Front-Mounted

Rotating Belt Tensioner CHT-ERU Front-Mounted — Chiaravalli CHT® tensioner (catalogue page 35).

  • E with belt tensioner roller RU double or triple). elastic elements. with assembly bolt. MOUNTED VERSION AVAILABLE REQUEST drawings available on www.chiaravalli.com quantity and prices on B2B Chiaravalli

Product Configuration

Select a row to add it to your quote

Code TypeRollerNewton A2Newton A1A ØBCDM Weight
94073521MF ERU 1 - 3035 Steel 0-90 0-110 30 mm 35 mm 51 mm 43 mm M8 0.33 kg
94073511MF ERU 1 - 3035 Polyamide 0-90 0-110 30 mm 35 mm 51 mm 43 mm M8 0.25 kg
94073501MF ERU 1 - 3035 Aluminium 0-90 0-110 30 mm 35 mm 51 mm 43 mm M8 0.27 kg
94074522MF ERU 1 - 4045 Steel 0-130 0-160 40 mm 45 mm 67 mm 56 mm M10 0.68 kg
94074512MF ERU 1 - 4045 Polyamide 0-130 0-160 40 mm 45 mm 67 mm 56 mm M10 0.53 kg
94074502MF ERU 1 - 4045 Aluminium 0-130 0-160 40 mm 45 mm 67 mm 56 mm M10 0.57 kg
94075022MF ERU 2 - 5050 Steel 0-130 0-160 50 mm 50 mm 69 mm 58 mm M12 0.95 kg
94075012MF ERU 2 - 5050 Polyamide 0-130 0-160 50 mm 50 mm 69 mm 58 mm M12 0.58 kg
94075002MF ERU 2 - 5050 Aluminium 0-130 0-160 50 mm 50 mm 69 mm 58 mm M12 0.64 kg
94074523MF ERU 3 - 4045 Steel 0-330 0-410 40 mm 45 mm 67 mm 57 mm M10 0.93 kg
94074513MF ERU 3 - 4045 Polyamide 0-330 0-410 40 mm 45 mm 67 mm 57 mm M10 0.78 kg
94074503MF ERU 3 - 4045 Aluminium 0-330 0-410 40 mm 45 mm 67 mm 57 mm M10 0.82 kg
94075023MF ERU 3 - 5050 Steel 0-330 0-410 50 mm 50 mm 69 mm 59 mm M12 1.2 kg
94075013MF ERU 3 - 5050 Polyamide 0-330 0-410 50 mm 50 mm 69 mm 59 mm M12 0.83 kg
94075003MF ERU 3 - 5050 Aluminium 0-330 0-410 50 mm 50 mm 69 mm 59 mm M12 0.89 kg
94076024MF ERU 4 - 6060 Steel 0-800 0-1000 60 mm 60 mm 89 mm 76 mm M12 2.98 kg
94076014MF ERU 4 - 6060 Polyamide 0-800 0-1000 60 mm 60 mm 89 mm 76 mm M12 2.24 kg
94076004MF ERU 4 - 6060 Aluminium 0-800 0-1000 60 mm 60 mm 89 mm 76 mm M12 2.35 kg
94078025MF ERU 5 - 8090 Steel 0-1500 0-1850 80 mm 90 mm 127 mm 109 mm M20 6.5 kg
94078015MF ERU 5 - 8090 Polyamide 0-1500 0-1850 80 mm 90 mm 127 mm 109 mm M20 4.4 kg
94078005MF ERU 5 - 8090 Aluminium 0-1500 0-1850 80 mm 90 mm 127 mm 109 mm M20 4.9 kg
94079013526MF ERU 6 - 90135 Steel 0-2500 0-3100 90 mm 135 mm 169 mm 154 mm M20 9.0 kg
94079016MF ERU 6 - 90135 Polyamide 0-2500 0-3100 90 mm 135 mm 169 mm 154 mm M20 8.2 kg
94079013506MF ERU 6 - 90135 Aluminium 0-2500 0-3100 90 mm 135 mm 169 mm 154 mm M20 7.5 kg
94079013517MF ERU 7 - 90135 Steel 0-3800 0-4800 90 mm 135 mm 169 mm 154 mm M20 12.0 kg
94079013527MF ERU 7 - 90135 Polyamide 0-3800 0-4800 90 mm 135 mm 169 mm 154 mm M20 10.7 kg
94079013507MF ERU 7 - 90135 Aluminium 0-3800 0-4800 90 mm 135 mm 169 mm 154 mm M20 11.0 kg
