Chiaravalli CHT® Rotating Tensioner CHT-ERU SS — product photo
Chiaravalli

CHT® Rotating Tensioner CHT-ERU SS

Rotating Tensioner CHT-ERU SS — Chiaravalli CHT® tensioner (catalogue page 50).

  • Tensioner E with belt tensioner roller in AISI 304 Stainless Steel
  • Rubber elastic elements
  • Supplied with AISI 304 Stainless Steel assembly bolt
  • Mirror finish. FRONT MOUNTED VERSION AVAILABLE UPON REQUEST

Product Configuration

Select a row to add it to your quote

Code TypeRollerNewton A2Newton A1A ØBCDM Weight CAD
94073521SS ERU 1 - 3035 Stainless steel 0-90 0-110 30 mm 35 mm 51 mm 43 mm M8 0.34 kg
94073511SS ERU 1 - 3035 Polyamide 0-90 0-110 30 mm 35 mm 51 mm 43 mm M8 0.27 kg
94074522SS ERU 2 - 4045 Stainless steel 0-130 0-160 40 mm 45 mm 67 mm 56 mm M10 0.8 kg
94074512SS ERU 2 - 4045 Polyamide 0-130 0-160 40 mm 45 mm 67 mm 56 mm M10 0.67 kg
94075022SS ERU 2 - 5050 Stainless steel 0-130 0-160 50 mm 50 mm 69 mm 58 mm M12 1.07 kg
94075012SS ERU 2 - 5050 Polyamide 0-130 0-160 50 mm 50 mm 69 mm 58 mm M12 68.0 kg
94074523SS ERU 3 - 4045 Stainless steel 0-330 0-410 40 mm 45 mm 67 mm 57 mm M10 0.97 kg
94074513SS ERU 3 - 4045 Polyamide 0-330 0-410 40 mm 45 mm 67 mm 57 mm M10 0.8 kg
94075023SS ERU 3 - 5050 Stainless steel 0-330 0-410 50 mm 50 mm 69 mm 59 mm M12 1.24 kg
94075013SS ERU 3 - 5050 Polyamide 0-330 0-410 50 mm 50 mm 69 mm 59 mm M12 0.85 kg
94076024SS ERU 4 - 6060 Stainless steel 0-800 0-1000 60 mm 60 mm 89 mm 76 mm M12 3.08 kg
94076014SS ERU 4 - 6060 Polyamide 0-800 0-1000 60 mm 60 mm 89 mm 76 mm M12 2.34 kg
94078024SS ERU 5 - 8080 Stainless steel 0-800 0-1000 80 mm 80 mm 92.5 mm 82.5 mm M12 5.84 kg
94078014SS ERU 5 - 8080 Polyamide 0-800 0-1000 80 mm 80 mm 92.5 mm 82.5 mm M12 2.6 kg
94078025SS ERU 5 - 8090 Stainless steel 0-1500 0-1850 80 mm 90 mm 127 mm 109 mm M20 5.85 kg
94078015SS ERU 5 - 8090 Polyamide 0-1500 0-1850 80 mm 90 mm 127 mm 109 mm M20 4.0 kg
9407901356SS ERU 6 - 90135 Stainless steel 0-2500 0-3100 90 mm 135 mm 169 mm 154 mm M20 12.4 kg
94079016SS ERU 6 - 90135 Polyamide 0-2500 0-3100 90 mm 135 mm 169 mm 154 mm M20 8.48 kg
94079013527SS ERU 7 - 90135 Stainless steel 0-3800 0-4800 90 mm 135 mm 169 mm 154 mm M20 15.89 kg
94079017SS ERU 7 - 90135 Polyamide 0-3800 0-4800 90 mm 135 mm 169 mm 154 mm M20 12.0 kg

Product Information

Material
AISI 304 stainless steel

Need help specifying this product?

Our technical team can help you specify the right component. Add it to your quote basket above, or contact us directly.
