Chiaravalli CHT® Tensioner CHT-ASRU SS — product photo
Chiaravalli

CHT® Tensioner CHT-ASRU SS

Tensioner CHT-ASRU SS — Chiaravalli CHT® tensioner (catalogue page 59).

  • AS INOX with head for accessory stainless steel bushings. expressed in N is obtained through “pressure” performed in the laboratory. loop cover plate. AISI 304 stainless steel, available in AISI 316 request. finish. available on www.chiaravalli.com quantity and prices on B2B Chiaravalli

Product Configuration

Select a row to add it to your quote

Code TypeRollerNewtonAB with metal sheetB without metal sheetC with metal sheetC without metal sheetD minD maxEFGHILM with metal sheetM without metal sheetNOPQRS CAD
94021235TSS CHT-ASRU1 3035 SS Stainless steel roller 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 34 mm 39.75 mm 13.9 mm M8 12.2 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 30 mm 3.3 mm 35 mm
94021135TSS CHT-ASRU1 3035 SS Polyamide roller 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 34 mm 39.75 mm 13.9 mm M8 12.2 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 30 mm 3.3 mm 35 mm
94021245TSS CHT-ASRU1 4045 SS Stainless steel roller 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 34 mm 39.75 mm 13.9 mm M10 12.2 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 40 mm 6.4 mm 45 mm
94021145TSS CHT-ASRU1 4045 SS Polyamide roller 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 34 mm 39.75 mm 13.9 mm M10 12.2 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 40 mm 6.4 mm 45 mm
94021250TSS CHT-ASRU1 5050 SS Stainless steel roller 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 34 mm 39.75 mm 13.9 mm M12 12.2 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 50 mm 2.5 mm 50 mm
94021150TSS CHT-ASRU1 5050 SS Polyamide roller 280 50 mm 26.5 mm 24.5 mm 76 mm 74 mm 103.1 mm 132.1 mm 34 mm 39.75 mm 13.9 mm M12 12.2 mm 20 mm 8.5 mm 6.5 mm 50 mm M10 x 45 52 mm 50 mm 2.5 mm 50 mm
94022250TSS CHT-ASRU2 5050 SS Stainless steel roller 460 65 mm 32 mm 30 mm 89 mm 87 mm 130 mm 164 mm 40 mm 50 mm 11 mm M12 14.7 mm 25 mm 8 mm 6 mm 60.5 mm M12 x 55 67 mm 50 mm 2.5 mm 50 mm
94022150TSS CHT-ASRU2 5050 SS Polyamide roller 460 65 mm 32 mm 30 mm 89 mm 87 mm 130 mm 164 mm 40 mm 50 mm 11 mm M12 14.7 mm 25 mm 8 mm 6 mm 60.5 mm M12 x 55 67 mm 50 mm 2.5 mm 50 mm
94023250TSS CHT-ASRU3 5050 SS Stainless steel roller 690 80 mm 37 mm 35 mm 106 mm 104 mm 161.7 mm 197.7 mm 55 mm 60 mm 11.3 mm M12 17.5 mm 30 mm 9 mm 7 mm 73 mm M14 x 60 80 mm 50 mm 2.5 mm 50 mm
94023150TSS CHT-ASRU3 5050 SS Polyamide roller 690 80 mm 37 mm 35 mm 106 mm 104 mm 161.7 mm 197.7 mm 55 mm 60 mm 11.3 mm M12 17.5 mm 30 mm 9 mm 7 mm 73 mm M14 x 60 80 mm 50 mm 2.5 mm 50 mm
94023260TSS CHT-ASRU3 6060 SS Stainless steel roller 690 80 mm 37 mm 106 mm 106 mm 104 mm 161.7 mm 197.7 mm 55 mm 60 mm 11.3 mm M12 17.5 mm 30 mm 9 mm 7 mm 73 mm M14 x 60 80 mm 60 mm 2.5 mm 60 mm
94023160TSS CHT-ASRU3 6060 SS Polyamide roller 690 80 mm 37 mm 106 mm 106 mm 104 mm 161.7 mm 197.7 mm 55 mm 60 mm 11.3 mm M12 17.5 mm 30 mm 9 mm 7 mm 73 mm M14 x 60 80 mm 60 mm 2.5 mm 60 mm

Product Information

Material
AISI 304 stainless steel
