Chiaravalli HTD® Taper-Lock® Timing Pulley 8M-50 (8 mm pitch, 50 mm belt) — product photo
Chiaravalli

HTD® Taper-Lock® Timing Pulley 8M-50 (8 mm pitch, 50 mm belt)

Timing Pulleys

HTD® 8M-50 timing pulley (8 mm pitch, for 50 mm belt width) for Taper-Lock® bush mounting, teeth Z 28–192. Material per size: Steel or Cast iron — see the Material column.

The Taper bush column gives the bush size; Bore max is the largest bore that bush accepts. The Exec. column refers to the execution figures on the dimension drawings (F executions are flanged).

Product Configuration

Select a row to add it to your quote

Code ZExec.Taper bushBore maxDpDeDf flangeDm hubDiFSPMaterial Weight CAD
41450028 28 2F 1210 32 mm 71.3 mm 70.08 mm 75 mm — 50 mm 60 mm 25 mm 35 mm Steel 0.6 kg
41450030 30 2F 1615 42 mm 76.39 mm 75.13 mm 82.5 mm — 58 mm 60 mm 38 mm 22 mm Steel 0.65 kg
41450032 32 2F 1615 42 mm 81.49 mm 80.16 mm 87 mm — 63 mm 60 mm 38 mm 22 mm Steel 0.8 kg
41450034 34 2F 1615 42 mm 86.58 mm 85.22 mm 91 mm — 65 mm 60 mm 38 mm 22 mm Steel 1.08 kg
41450036 36 2F 1615 42 mm 91.67 mm 90.3 mm 97 mm — 68 mm 60 mm 38 mm 22 mm Steel 1.35 kg
41450038 38 2F 1615 42 mm 96.77 mm 95.39 mm 102 mm — 72 mm 60 mm 38 mm 22 mm Steel 1.65 kg
41450040 40 3F 2012 50 mm 101.86 mm 100.49 mm 106 mm — 80 mm 60 mm 32 mm 14 mm Steel 1.7 kg
41450044 44 3F 2012 50 mm 112.05 mm 110.67 mm 120 mm — 86 mm 60 mm 32 mm 14 mm Steel 1.8 kg
41450048 48 3F 2012 50 mm 122.23 mm 120.86 mm 128 mm — 95 mm 60 mm 32 mm 14 mm Steel 2.35 kg
41450056 56 3F 2517 60 mm 142.6 mm 141.23 mm 150 mm — 116 mm 60 mm 45 mm 7.5 mm Steel 3.35 kg
41450064 64 3F 2517 60 mm 162.97 mm 161.6 mm 168 mm — 136 mm 60 mm 45 mm 7.5 mm Steel 4.9 kg
41450072 72 10F 2517 60 mm 183.35 mm 181.97 mm 192 mm 125 mm 158 mm 60 mm 45 mm 7.5 mm Steel 6.9 kg
41450080 80 4 3020 75 mm 203.72 mm 202.3 mm — — 180 mm 60 mm 51 mm 4.5 mm Cast iron 8.9 kg
41450090 90 11 3020 75 mm 229.18 mm 227.81 mm — 160 mm 204 mm 60 mm 51 mm 4.5 mm Cast iron 9.9 kg
41450112 112 11 3020 75 mm 285.21 mm 283.83 mm — 170 mm 254 mm 60 mm 51 mm 4.5 mm Cast iron 12.1 kg
41450144 144 12 3020 75 mm 366.69 mm 365.32 mm — 170 mm 336 mm 60 mm 51 mm 4.5 mm Cast iron 15.4 kg
41450168 168 13 3525 90 mm 427.81 mm 426.44 mm — 198 mm 395 mm 60 mm 65 mm 2.5 mm Cast iron 22.8 kg
41450192 192 13 3525 90 mm 488.92 mm 487.55 mm — 198 mm 455 mm 60 mm 65 mm 2.5 mm Cast iron 26.5 kg

Product Information

Pitch
8.0 mm
