Chiaravalli HTD® Taper-Lock® Timing Pulley 8M-85 (8 mm pitch, 85 mm belt) — product photo
Chiaravalli

HTD® Taper-Lock® Timing Pulley 8M-85 (8 mm pitch, 85 mm belt)

Timing Pulleys

HTD® 8M-85 timing pulley (8 mm pitch, for 85 mm belt width) for Taper-Lock® bush mounting, teeth Z 34–192. Material per size: Steel or Cast iron — see the Material column.

The Taper bush column gives the bush size; Bore max is the largest bore that bush accepts. The Exec. column refers to the execution figures on the dimension drawings (F executions are flanged).

Product Configuration

Select a row to add it to your quote

Code ZExec.Taper bushBore maxDpDeDf flangeDm hubDiFSPMaterial Weight CAD
41485034 34 3F 1615 42 mm 86.58 mm 85.22 mm 91 mm — 65 mm 95 mm 38 mm 28.5 mm Steel 1.5 kg
41485036 36 3F 1615 42 mm 91.67 mm 90.3 mm 97 mm — 68 mm 95 mm 38 mm 28.5 mm Steel 1.9 kg
41485038 38 3F 1615 42 mm 96.77 mm 95.39 mm 102 mm — 72 mm 95 mm 38 mm 28.5 mm Steel 2.2 kg
41485040 40 3F 2012 50 mm 101.86 mm 100.49 mm 106 mm — 80 mm 95 mm 32 mm 31.5 mm Steel 1.9 kg
41485044 44 3F 2012 50 mm 112.05 mm 110.67 mm 120 mm — 86 mm 95 mm 32 mm 31.5 mm Steel 2.3 kg
41485048 48 3F 2517 60 mm 122.23 mm 120.86 mm 128 mm — 97 mm 95 mm 45 mm 25 mm Steel 2.7 kg
41485056 56 3F 2517 60 mm 142.6 mm 141.23 mm 150 mm — 116 mm 95 mm 45 mm 25 mm Steel 4.5 kg
41485064 64 3F 2517 60 mm 162.97 mm 161.6 mm 168 mm — 136 mm 95 mm 45 mm 25 mm Steel 6.3 kg
41485072 72 3F 3020 75 mm 183.35 mm 181.97 mm 192 mm — 150 mm 95 mm 51 mm 22 mm Steel 8.1 kg
41485080 80 4 3020 75 mm 203.72 mm 202.35 mm — — 180 mm 95 mm 51 mm 22 mm Cast iron 10.2 kg
41485090 90 4 3020 75 mm 229.18 mm 227.81 mm — — 204 mm 95 mm 51 mm 22 mm Cast iron 11.2 kg
41485112 112 11 3020 75 mm 285.21 mm 283.83 mm — 170 mm 254 mm 95 mm 51 mm 22 mm Cast iron 15.0 kg
41485144 144 11 3525 90 mm 366.69 mm 365.32 mm — 198 mm 336 mm 95 mm 65 mm 15 mm Cast iron 20.2 kg
41485168 168 12 3525 90 mm 427.81 mm 426.44 mm — 198 mm 395 mm 95 mm 65 mm 15 mm Cast iron 22.4 kg
41485192 192 12 3525 90 mm 488.92 mm 487.55 mm — 198 mm 455 mm 95 mm 65 mm 15 mm Cast iron 28.2 kg

Product Information

Pitch
8.0 mm
