Chiaravalli Standard Bevel Gear M3.5 1:4
Chiaravalli

Standard Bevel Gear M3.5 1:4

Bevel Gears · M3.5 1:4

Product Configuration

Select a row to add it to your quote

Code ZdpdeFAdmD1LVSLm Weight CAD
32351416 16 56 mm 62.8 mm 25 mm 45 mm 48 mm 15 mm 43 mm 87.1 mm 2 mm 19.1 mm 0.48 kg
33351464 64 224 mm 225.7 mm 25 mm 50 mm 100 mm 20 mm 43 mm 19.28 mm 7 mm 22 mm 7.53 kg

Product Information

Module (m)
3.5
Pressure Angle (α)
20°
Bevel Type
Standard
Ratio (i)
1:4
Standard
UNI 6588
Material
C45 UNI 7847

Cross-References

Also Known As

  • bevel gear M3.5 1:4
  • standard bevel M3.5
  • M3.5 ratio 1:4 bevel
