Chiaravalli V-Belt Pulley for Locking Devices SPA 2 Grooves — product photo
Chiaravalli

V-Belt Pulley for Locking Devices SPA 2 Grooves

Cast-iron SPA V-belt pulley with 2 grooves, bored Ø55, Ø65 or Ø80 H8 to take a shaft locking element. Execution D = disc, R = spokes, P = solid (P/1 solid with the hub on one side), as drawn.

Product Configuration

Select a row to add it to your quote

Code DpBore ØExec.FLØ MRØ DiS Weight CAD
91250902 90 mm 55 H8 mm P 35 mm — — — — — 0.2 kg
91250952 95 mm 55 H8 mm P 35 mm — — — — — 0.85 kg
91251002 100 mm 55 H8 mm P 35 mm — — — — — 0.9 kg
91261002 100 mm 65 H8 mm P 35 mm — — — — — 0.9 kg
91251052 105 mm 55 H8 mm P 35 mm — — — — — 0.95 kg
91251202 120 mm 55 H8 mm P/1 35 mm 27 mm — 8 mm 88 mm — 1.0 kg
91261252 125 mm 65 H8 mm P/1 35 mm 27 mm — 8 mm 92 mm — 1.0 kg
91251502 150 mm 55 H8 mm P/1 35 mm 27 mm — 8 mm 117 mm — 1.35 kg
91251602 160 mm 55 H8 mm P/1 35 mm 27 mm — 8 mm 127 mm — 1.5 kg
91261602 160 mm 65 H8 mm P/1 35 mm 27 mm — 8 mm 127 mm — 1.5 kg
91251702 170 mm 55 H8 mm D 35 mm 27 mm — 4 mm 137 mm 27 mm 1.6 kg
91251802 180 mm 55 H8 mm D 35 mm 27 mm — 4 mm 147 mm 27 mm 1.7 kg
91261802 180 mm 65 H8 mm D 35 mm 27 mm — 4 mm 147 mm 27 mm 1.7 kg
91261902 190 mm 65 H8 mm D 35 mm 27 mm 120 mm 4 mm 157 mm 12 mm 1.8 kg
91252002 200 mm 55 H8 mm D 35 mm 27 mm 120 mm 4 mm 167 mm 12 mm 1.9 kg
91262002 200 mm 65 H8 mm D 35 mm 27 mm 120 mm 4 mm 167 mm 12 mm 1.9 kg
91252252 225 mm 55 H8 mm D 35 mm 27 mm 120 mm 4 mm 192 mm 12 mm 2.2 kg
91262252 225 mm 65 H8 mm D 35 mm 27 mm 120 mm 4 mm 192 mm 12 mm 2.2 kg
91252502 250 mm 55 H8 mm R 35 mm 27 mm 130 mm 4 mm 217 mm 14 mm 2.8 kg

Product Information

Material
Cast iron
