Chiaravalli V-Belt Pulley for Locking Devices SPA 3 Grooves — product photo
Chiaravalli

V-Belt Pulley for Locking Devices SPA 3 Grooves

Cast-iron SPA V-belt pulley with 3 grooves, bored Ø55, Ø65 or Ø80 H8 to take a shaft locking element. Execution D = disc, R = spokes, P = solid (P/1 solid with the hub on one side), as drawn.

Product Configuration

Select a row to add it to your quote

Code DpBore ØExec.FLØ MRØ DiS Weight CAD
91250903 90 mm 55 H8 mm P 50 mm — — — — — 1.1 kg
91251003 100 mm 55 H8 mm P 50 mm — — — — — 1.3 kg
91261253 125 mm 65 H8 mm P/1 50 mm 27 mm — 23 mm 92 mm — 1.8 kg
91261303 130 mm 65 H8 mm P/1 50 mm 27 mm — 23 mm 97 mm — 1.75 kg
91261603 160 mm 65 H8 mm P/1 50 mm 27 mm — 23 mm 127 mm — 1.9 kg
91251803 180 mm 55 H8 mm D 50 mm 27 mm — 11.5 mm 147 mm 27 mm 2.4 kg
91271803 180 mm 65 H8 mm D 50 mm 27 mm — 11.5 mm 147 mm 27 mm 2.4 kg
91261903 190 mm 65 H8 mm D 50 mm 27 mm 120 mm 11.5 mm 157 mm 12 mm 2.5 kg
91262003 200 mm 65 H8 mm D 50 mm 27 mm 120 mm 11.5 mm 167 mm 14 mm 2.6 kg
91252253 225 mm 55 H8 mm D 50 mm 27 mm 120 mm 11.5 mm 192 mm 14 mm 2.8 kg
91262253 225 mm 65 H8 mm D 50 mm 27 mm 120 mm 11.5 mm 192 mm 14 mm 2.8 kg
91282503 250 mm 80 H8 mm R 50 mm 27 mm 130 mm 11.5 mm 217 mm 14 mm 3.5 kg

Product Information

Material
Cast iron
