Chiaravalli V-Belt Pulley for Locking Devices SPB 1 Groove — product photo
Chiaravalli

V-Belt Pulley for Locking Devices SPB 1 Groove

Cast-iron SPB V-belt pulley with 1 groove, bored Ø55, Ø65 or Ø80 H8 to take a shaft locking element. Execution D = disc, R = spokes, P = solid (P/1 solid with the hub on one side), as drawn.

Product Configuration

Select a row to add it to your quote

Code DpBore ØExec.FLØ MRØ DiS Weight CAD
91351121 112 mm 55 H8 mm P 25 mm — — — — — 1.5 kg
91351251 125 mm 55 H8 mm P 25 mm — — — — — 1.9 kg
91351501 150 mm 55 H8 mm P 25 mm — — — — — 2.4 kg
91361501 150 mm 65 H8 mm P 25 mm — — — — — 2.4 kg
91351601 160 mm 55 H8 mm P 25 mm — — — — — 2.5 kg
91361601 160 mm 65 H8 mm P 25 mm — — — — — 2.5 kg
91361901 190 mm 65 H8 mm P 25 mm — — — — — 3.5 kg
91362001 200 mm 65 H8 mm P 25 mm — — — — — 4.0 kg
91382001 200 mm 80 H8 mm P 25 mm — — — — — 4.0 kg
91352501 250 mm 55 H8 mm D 25 mm 25 mm 130 mm — 208 mm 16 mm 6.2 kg
91353001 300 mm 55 H8 mm R 25 mm 25 mm 130 mm — 258 mm 15 mm 7.0 kg
91353551 355 mm 55 H8 mm R 25 mm 25 mm 130 mm — 308 mm 16 mm 16.0 kg

Product Information

Material
Cast iron
