Chiaravalli V-Belt Pulley for Locking Devices SPB 2 Grooves — product photo
Chiaravalli

V-Belt Pulley for Locking Devices SPB 2 Grooves

Cast-iron SPB V-belt pulley with 2 grooves, bored Ø55, Ø65 or Ø80 H8 to take a shaft locking element. Execution D = disc, R = spokes, P = solid (P/1 solid with the hub on one side), as drawn.

Product Configuration

Select a row to add it to your quote

Code DpBore ØExec.FLØ MRØ DiS Weight CAD
91351122 112 mm 55 H8 mm P/1 44 mm 27 mm — 17 mm 70 mm — 1.9 kg
91361202 120 mm 65 H8 mm P/1 44 mm 27 mm — 17 mm 78 mm — 2.1 kg
91371252 125 mm 65 H8 mm P/1 44 mm 27 mm — 17 mm 83 mm — 2.4 kg
91361302 130 mm 65 H8 mm P/1 44 mm 27 mm — 17 mm 90 mm — 2.6 kg
91381302 130 mm 80 H8 mm P/1 44 mm 27 mm — 17 mm 90 mm — 2.6 kg
91351402 140 mm 55 H8 mm P/1 44 mm 27 mm — 17 mm 98 mm — 2.9 kg
91361402 140 mm 65 H8 mm P/1 44 mm 27 mm — 17 mm 98 mm — 2.9 kg
91381402 140 mm 80 H8 mm P/1 44 mm 27 mm — 17 mm 98 mm — 2.9 kg
91351502 150 mm 55 H8 mm P/1 44 mm 27 mm — 17 mm 108 mm — 3.2 kg
91361502 150 mm 65 H8 mm P/1 44 mm 27 mm — 17 mm 108 mm — 3.2 kg
91381502 150 mm 80 H8 mm P/1 44 mm 27 mm — 17 mm 108 mm — 3.2 kg
91361602 160 mm 65 H8 mm P/1 44 mm 27 mm — 17 mm 118 mm — 3.3 kg
91381602 160 mm 80 H8 mm P/1 44 mm 27 mm — 17 mm 118 mm — 3.3 kg
91381702 170 mm 80 H8 mm D 44 mm 27 mm — 8.5 mm 128 mm 27 mm 3.4 kg
91361802 180 mm 65 H8 mm D 44 mm 27 mm — 8.5 mm 138 mm 27 mm 3.9 kg
91381802 180 mm 80 H8 mm D 44 mm 27 mm — 8.5 mm 138 mm 27 mm 3.9 kg
91381902 190 mm 80 H8 mm D 44 mm 27 mm — 8.5 mm 148 mm 27 mm 6.5 kg
91372002 200 mm 65 H8 mm D 44 mm 27 mm 120 mm 8.5 mm 158 mm 15 mm 7.0 kg
91382002 200 mm 80 H8 mm D 44 mm 27 mm 120 mm 8.5 mm 158 mm 15 mm 7.0 kg
91362122 212 mm 65 H8 mm D 44 mm 27 mm 120 mm 8.5 mm 170 mm 15 mm 7.0 kg
91382122 212 mm 80 H8 mm D 44 mm 27 mm 120 mm 8.5 mm 170 mm 15 mm 7.0 kg
91372252 225 mm 65 H8 mm D 44 mm 27 mm 120 mm 8.5 mm 183 mm 15 mm 7.7 kg
91382252 225 mm 80 H8 mm D 44 mm 27 mm 120 mm 8.5 mm 183 mm 15 mm 7.7 kg
91352502 250 mm 55 H8 mm D 44 mm 27 mm 130 mm 8.5 mm 208 mm 16 mm 8.5 kg
91372502 250 mm 65 H8 mm D 44 mm 27 mm 130 mm 8.5 mm 208 mm 16 mm 8.5 kg
91382502 250 mm 80 H8 mm D 44 mm 27 mm 130 mm 8.5 mm 208 mm 16 mm 8.5 kg
91382802 280 mm 80 H8 mm D 44 mm 27 mm 120 mm 8.5 mm 238 mm 16 mm 10.0 kg

Product Information

Material
Cast iron
