Chiaravalli V-Belt Pulley for Locking Devices SPB 3 Grooves — product photo
Chiaravalli

V-Belt Pulley for Locking Devices SPB 3 Grooves

Cast-iron SPB V-belt pulley with 3 grooves, bored Ø55, Ø65 or Ø80 H8 to take a shaft locking element. Execution D = disc, R = spokes, P = solid (P/1 solid with the hub on one side), as drawn.

Product Configuration

Select a row to add it to your quote

Code DpBore ØExec.FLØ MRØ DiS Weight CAD
91361203 120 mm 65 H8 mm P/1 63 mm 27 mm — 36 mm 78 mm — 3.8 kg
91361253 125 mm 65 H8 mm P/1 63 mm 27 mm — 36 mm 83 mm — 4.0 kg
91361303 130 mm 65 H8 mm P/1 63 mm 27 mm — 36 mm 90 mm — 4.2 kg
91381303 130 mm 80 H8 mm P/1 63 mm 27 mm — 36 mm 90 mm — 4.2 kg
91361403 140 mm 65 H8 mm P/1 63 mm 27 mm — 36 mm 98 mm — 4.4 kg
91381403 140 mm 80 H8 mm P/1 63 mm 27 mm — 36 mm 98 mm — 4.4 kg
91361503 150 mm 65 H8 mm P/1 63 mm 27 mm — 36 mm 108 mm — 4.6 kg
91381503 150 mm 80 H8 mm P/1 63 mm 27 mm — 36 mm 108 mm — 4.6 kg
91361603 160 mm 65 H8 mm P/1 63 mm 27 mm — 36 mm 118 mm — 4.8 kg
91381603 160 mm 80 H8 mm P/1 63 mm 27 mm — 36 mm 118 mm — 4.8 kg
91361703 170 mm 65 H8 mm D 63 mm 27 mm — 18 mm 128 mm 27 mm 5.1 kg
91381703 170 mm 80 H8 mm D 63 mm 27 mm — 18 mm 128 mm 27 mm 5.1 kg
91361803 180 mm 65 H8 mm D 63 mm 27 mm — 18 mm 138 mm 27 mm 5.2 kg
91381803 180 mm 80 H8 mm D 63 mm 27 mm — 18 mm 138 mm 27 mm 5.2 kg
91381903 190 mm 80 H8 mm D 63 mm 27 mm — 18 mm 148 mm 27 mm 7.0 kg
91362003 200 mm 65 H8 mm D 63 mm 27 mm 120 mm 18 mm 158 mm 15 mm 8.0 kg
91382003 200 mm 80 H8 mm D 63 mm 27 mm 120 mm 18 mm 158 mm 15 mm 8.0 kg
91362123 212 mm 65 H8 mm D 63 mm 27 mm 120 mm 18 mm 170 mm 15 mm 8.5 kg
91382123 212 mm 80 H8 mm D 63 mm 27 mm 120 mm 18 mm 170 mm 15 mm 8.5 kg
91352253 225 mm 55 H8 mm D 63 mm 27 mm 120 mm 18 mm 183 mm 15 mm 9.0 kg
91362253 225 mm 65 H8 mm D 63 mm 27 mm 120 mm 18 mm 183 mm 15 mm 9.0 kg
91382253 225 mm 80 H8 mm D 63 mm 27 mm 120 mm 18 mm 183 mm 15 mm 9.0 kg
91382403 240 mm 80 H8 mm D 63 mm 27 mm 120 mm 18 mm 198 mm 16 mm 11.0 kg
91372503 250 mm 65 H8 mm D 63 mm 27 mm 130 mm 18 mm 208 mm 16 mm 11.0 kg
91382503 250 mm 80 H8 mm D 63 mm 27 mm 130 mm 18 mm 208 mm 16 mm 11.0 kg
91382803 280 mm 80 H8 mm D 63 mm 27 mm 120 mm 18 mm 238 mm 16 mm 12.5 kg
91363153 315 mm 65 H8 mm R 63 mm 27 mm 130 mm 18 mm 273 mm 18 mm 14.0 kg

Product Information

Material
Cast iron
