Chiaravalli V-Belt Pulley for Locking Devices SPB 5 Grooves — product photo
Chiaravalli

V-Belt Pulley for Locking Devices SPB 5 Grooves

Cast-iron SPB V-belt pulley with 5 grooves, bored Ø55, Ø65 or Ø80 H8 to take a shaft locking element. Execution D = disc, R = spokes, P = solid (P/1 solid with the hub on one side), as drawn.

Product Configuration

Select a row to add it to your quote

Code DpBore ØExec.FLØ MRØ DiS Weight CAD
91381305 130 mm 80 H8 mm P/1 101 mm 27 mm — 74 mm 90 mm — 5.5 kg
91381405 140 mm 80 H8 mm P/1 101 mm 27 mm — 74 mm 98 mm — 5.8 kg
91381505 150 mm 80 H8 mm P/1 101 mm 27 mm — 74 mm 108 mm — 6.0 kg
91381605 160 mm 80 H8 mm P/1 101 mm 27 mm — 74 mm 118 mm — 7.0 kg
91381705 170 mm 80 H8 mm D 101 mm 27 mm — 37 mm 128 mm 27 mm 7.4 kg
91381805 180 mm 80 H8 mm D 101 mm 27 mm — 37 mm 138 mm 27 mm 7.5 kg
91381905 190 mm 80 H8 mm D 101 mm 27 mm — 37 mm 148 mm 27 mm 9.0 kg
91382005 200 mm 80 H8 mm D 101 mm 27 mm 120 mm 37 mm 158 mm 15 mm 10.0 kg
91382125 212 mm 80 H8 mm D 101 mm 27 mm 120 mm 37 mm 170 mm 15 mm 11.0 kg
91382255 225 mm 80 H8 mm D 101 mm 27 mm 120 mm 37 mm 183 mm 15 mm 11.5 kg
91382505 250 mm 80 H8 mm D 101 mm 27 mm 130 mm 37 mm 208 mm 16 mm 18.0 kg
91382805 280 mm 80 H8 mm D 101 mm 27 mm 130 mm 37 mm 238 mm 16 mm 21.0 kg
91383005 300 mm 80 H8 mm R 101 mm 27 mm 130 mm 37 mm 258 mm 22 mm 19.0 kg
91383155 315 mm 80 H8 mm R 101 mm 27 mm 130 mm 37 mm 273 mm 22 mm 22.0 kg

Product Information

Material
Cast iron
