Chiaravalli V-Belt Pulley for Locking Devices SPB 6 Grooves — product photo
Chiaravalli

V-Belt Pulley for Locking Devices SPB 6 Grooves

Cast-iron SPB V-belt pulley with 6 grooves, bored Ø55, Ø65 or Ø80 H8 to take a shaft locking element. Execution D = disc, R = spokes, P = solid (P/1 solid with the hub on one side), as drawn.

Product Configuration

Select a row to add it to your quote

Code DpBore ØExec.FLØ MRØ DiS Weight CAD
91381306 130 mm 80 H8 mm P/1 120 mm 27 mm — 93 mm 90 mm — 6.0 kg
91381606 160 mm 80 H8 mm P/1 120 mm 27 mm — 93 mm 118 mm — 8.3 kg
91381806 180 mm 80 H8 mm D 120 mm 27 mm — 46.5 mm 138 mm 27 mm 8.9 kg
91382006 200 mm 80 H8 mm D 120 mm 27 mm 120 mm 46.5 mm 158 mm 18 mm 11.0 kg
91382256 225 mm 80 H8 mm D 120 mm 27 mm 120 mm 46.5 mm 183 mm 18 mm 13.0 kg
91382506 250 mm 80 H8 mm D 120 mm 27 mm 130 mm 46.5 mm 208 mm 18 mm 22.0 kg

Product Information

Material
Cast iron
