Chiaravalli V-Belt Pulley for Locking Devices SPC 3 Grooves — product photo
Chiaravalli

V-Belt Pulley for Locking Devices SPC 3 Grooves

Cast-iron SPC V-belt pulley with 3 grooves, bored Ø55, Ø65 or Ø80 H8 to take a shaft locking element. Execution D = disc, R = spokes, P = solid (P/1 solid with the hub on one side), as drawn.

Product Configuration

Select a row to add it to your quote

Code DpBore ØExec.FLØ MRØ DiS Weight CAD
91481603 160 mm 80 H8 mm P/1 85 mm 27 mm — 58 mm 103 mm — 2.6 kg
91481903 190 mm 80 H8 mm P/1 85 mm 27 mm — 58 mm 133 mm — 2.9 kg
91482253 225 mm 80 H8 mm D 85 mm 27 mm 120 mm 29 mm 168 mm 25 mm 3.4 kg

Product Information

Material
Cast iron
