Chiaravalli V-Belt Pulley Pilot Bore SPC 1 Groove — product photo
Chiaravalli

V-Belt Pulley Pilot Bore SPC 1 Groove

Cast-iron solid-hub SPC V-belt pulley with 1 groove, supplied with a pilot bore (d H9) for machining to size. Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPONLDSBTyped H9 Weight CAD
91421201 SPC120-1 120 mm 129.6 mm 65 mm 50 mm — — 34 mm 1 15 mm 2.66 kg
91421401 SPC140-1 140 mm 149.6 mm 70 mm 50 mm — — 34 mm 1 20 mm 3.55 kg
91421501 SPC150-1 150 mm 159.6 mm 70 mm 50 mm — — 34 mm 1 20 mm 4.09 kg
91421601 SPC160-1 160 mm 169.6 mm 72 mm 50 mm — — 34 mm 1 20 mm 4.68 kg
91421801 SPC180-1 180 mm 189.6 mm 76 mm 50 mm 123 mm 16 mm 34 mm 3 20 mm 5.05 kg
91422001 SPC200-1 200 mm 209.6 mm 76 mm 50 mm 143 mm 16 mm 34 mm 3 20 mm 5.85 kg
91422251 SPC225-1 225 mm 234.6 mm 86 mm 50 mm 168 mm 16 mm 34 mm 3 20 mm 7.2 kg
91422501 SPC250-1 250 mm 259.6 mm 86 mm 50 mm 193 mm 16 mm 34 mm 3 20 mm 8.51 kg
91422801 SPC280-1 280 mm 289.6 mm 86 mm 50 mm 223 mm 16 mm 34 mm 3 20 mm 10.18 kg
91423001 SPC300-1 300 mm 309.6 mm 86 mm 50 mm 243 mm 16 mm 34 mm 3 20 mm 11.76 kg

Product Information

Material
Cast iron
