Chiaravalli V-Belt Pulley PPV-L Micro-V 8 Grooves — product photo
Chiaravalli

V-Belt Pulley PPV-L Micro-V 8 Grooves

PPV-L Micro-V pulley with 8 grooves, pitch 4.7 ± 0.05 mm, F 48 ± 0.1 mm, P 7.55 mm. Executions 1–8 as drawn; small diameters are solid with a pilot bore, larger ones take a taper bush.

Product Configuration

Select a row to add it to your quote

Code DeExec.BushSZDmU Weight CAD
48208075 75 mm 3 1210 26 mm 22 mm — 56 mm 0.66 kg
48208080 80 mm 3 1210 26 mm 22 mm — 56 mm 0.86 kg
48208085 85 mm 3 1210 26 mm 22 mm — 61 mm 1.0 kg
48208090 90 mm 3 1610 26 mm 22 mm — 66 mm 1.01 kg
48208095 95 mm 3 1610 26 mm 22 mm — 71 mm 1.16 kg
48208100 100 mm 3 1610 26 mm 22 mm — 76 mm 1.31 kg
48208106 106 mm 3 1610 26 mm 22 mm — 82 mm 1.53 kg
48208112 112 mm 3 1610 26 mm 22 mm — 88 mm 1.75 kg
48208118 118 mm 3 2012 32 mm 16 mm — 94 mm 1.88 kg
48208125 125 mm 3 2012 32 mm 16 mm — 101 mm 2.22 kg
48208132 132 mm 3 2012 32 mm 16 mm — 108 mm 2.54 kg
48208140 140 mm 3 2517 45 mm 3 mm 82 mm 116 mm 3.02 kg
48208150 150 mm 3 2517 45 mm 3 mm — 126 mm 3.75 kg
48208160 160 mm 3 2517 45 mm 3 mm — 136 mm 4.54 kg
48208170 170 mm 3 2517 45 mm 3 mm — 146 mm 5.35 kg
48208180 180 mm 7 2517 45 mm 1.5 mm 120 mm 156 mm 4.52 kg
48208200 200 mm 7 2517 45 mm 1.5 mm 120 mm 176 mm 5.07 kg
48208224 224 mm 7 2517 45 mm 1.5 mm 120 mm 202 mm 9.77 kg
48208250 250 mm 8 3020 52 mm 2 mm 146 mm 228 mm 13.12 kg
48208280 280 mm 8 3020 52 mm 2 mm 146 mm 256 mm 18.18 kg
48208315 315 mm 8 3020 52 mm 2 mm 146 mm 285 mm 24.82 kg

Product Information

Pitch
4.7 mm
