Chiaravalli V-Belt Pulley for Taper Bushes SPA 3 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPA 3 Grooves

Cast-iron SPA V-belt pulley with 3 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91200713 SPA71-03 71 mm 76.5 mm 8 1108 28 mm — 50 mm 40 mm 28 mm 22 mm — — 0.7 kg
91200753 SPA75-03 75 mm 80.5 mm 8 1108 28 mm — 50 mm 44 mm 28 mm 22 mm — — 0.8 kg
91200803 SPA80-03 80 mm 85.5 mm 8 1210 32 mm — 50 mm 50 mm 25 mm 25 mm — — 0.8 kg
91200853 SPA85-03 85 mm 90.5 mm 8 1210 32 mm — 50 mm 55 mm 25 mm 25 mm — — 0.94 kg
91200903 SPA90-03 90 mm 95.5 mm 8 1610 42 mm — 50 mm 59 mm 25 mm 25 mm — — 0.95 kg
91200953 SPA95-03 95 mm 100.5 mm 8 1610 42 mm — 50 mm 63 mm 25 mm 25 mm — — 1.12 kg
91201003 SPA100-03 100 mm 105.5 mm 2 1610 42 mm — 50 mm 66 mm — 25 mm 25 mm — 1.3 kg
91201063 SPA106-03 106 mm 111.5 mm 2 1610 42 mm — 50 mm 72 mm — 25 mm 25 mm — 1.52 kg
91201123 SPA112-03 112 mm 117.5 mm 8 2012 50 mm — 50 mm 78 mm 18 mm 32 mm — — 1.57 kg
91201183 SPA118-03 118 mm 123.5 mm 2 2012 50 mm — 50 mm 84 mm — 32 mm 18 mm — 1.85 kg
91201253 SPA125-03 125 mm 130.5 mm 2 2012 50 mm — 50 mm 91 mm — 32 mm 18 mm — 2.2 kg
91201323 SPA132-03 132 mm 137.5 mm 2 2012 50 mm — 50 mm 98 mm — 32 mm 18 mm — 2.53 kg
91201403 SPA140-03 140 mm 145.5 mm 8 2517 60 mm — 50 mm 106 mm 5 mm 45 mm — — 2.87 kg
91201503 SPA150-03 150 mm 155.5 mm 8 2517 60 mm — 50 mm 116 mm 5 mm 45 mm — — 3.55 kg
91201603 SPA160-03 160 mm 165.5 mm 8 2517 60 mm — 50 mm 125 mm 5 mm 45 mm — — 4.33 kg
91201703 SPA170-03 170 mm 175.5 mm 8 2517 60 mm — 50 mm 135 mm 5 mm 45 mm — — 5.1 kg
91201803 SPA180-03 180 mm 185.5 mm 8 2517 60 mm — 50 mm 146 mm 5 mm 45 mm — — 6.0 kg
91201903 SPA190-03 190 mm 195.5 mm 8 2517 60 mm — 50 mm 156 mm 5 mm 45 mm — — 6.92 kg
91202003 SPA200-03 200 mm 205.5 mm 6 2517 60 mm 20 mm 50 mm 165 mm 2.5 mm 45 mm 2.5 mm 123 mm 6.15 kg
91202123 SPA212-03 212 mm 217.5 mm 5 2517 60 mm — 50 mm 177 mm 2.5 mm 45 mm 2.5 mm 123 mm 6.03 kg
91202243 SPA224-03 224 mm 229.5 mm 5 2517 60 mm — 50 mm 189 mm 2.5 mm 45 mm 2.5 mm 124 mm 6.4 kg
91202363 SPA236-03 236 mm 241.5 mm 5 2517 60 mm — 50 mm 202 mm 2.5 mm 45 mm 2.5 mm 124 mm 6.8 kg
91202503 SPA250-03 250 mm 255.5 mm 5 2517 60 mm — 50 mm 215 mm 2.5 mm 45 mm 2.5 mm 124 mm 7.25 kg
91202803 SPA280-03 280 mm 285.5 mm 5 2517 60 mm — 50 mm 245 mm 2.5 mm 45 mm 2.5 mm 124 mm 8.15 kg
91203003 SPA300-03 300 mm 305.5 mm 4 3020 75 mm — 50 mm 265 mm 0.5 mm 51 mm 0.5 mm 150 mm 10.04 kg
91203153 SPA315-03 315 mm 320.5 mm 4 3020 75 mm — 50 mm 280 mm 0.5 mm 51 mm 0.5 mm 159 mm 11.32 kg
91203353 SPA335-03 335 mm 340.5 mm 4 3020 75 mm — 50 mm 300 mm 0.5 mm 51 mm 0.5 mm 159 mm 12.04 kg
91203553 SPA355-03 355 mm 360.5 mm 4 3020 75 mm — 50 mm 320 mm 0.5 mm 51 mm 0.5 mm 159 mm 12.75 kg
91204003 SPA400-03 400 mm 405.5 mm 4 3020 75 mm — 50 mm 365 mm — 51 mm 1 mm 159 mm 14.46 kg
91204503 SPA450-03 450 mm 455.5 mm 4 3020 75 mm — 50 mm 415 mm — 51 mm 1 mm 159 mm 16.7 kg
91205003 SPA500-03 500 mm 505.5 mm 4 3020 75 mm — 50 mm 465 mm — 51 mm 1 mm 159 mm 19.17 kg
91205603 SPA560-03 560 mm 565.5 mm 4 3020 75 mm — 50 mm 525 mm — 51 mm 1 mm 159 mm 21.45 kg
91206303 SPA630-03 630 mm 635.5 mm 4 3020 75 mm — 50 mm 595 mm — 51 mm 1 mm 159 mm 25.2 kg
91208003 SPA800-03 800 mm 805.5 mm 4 3535 90 mm — 50 mm 765 mm 19.5 mm 89 mm 19.5 mm 175 mm 40.0 kg

Product Information

Material
Cast iron
