Chiaravalli V-Belt Pulley for Taper Bushes SPA 4 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPA 4 Grooves

Cast-iron SPA V-belt pulley with 4 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91200954 SPA95-04 95 mm 100.5 mm 8 1615 42 mm — 65 mm 63 mm 27 mm 38 mm — — 1.5 kg
91201004 SPA100-04 100 mm 105.5 mm 2 1615 42 mm — 65 mm 66 mm — 38 mm 27 mm — 1.75 kg
91201064 SPA106-04 106 mm 111.5 mm 8 2012 50 mm — 65 mm 72 mm 33 mm 32 mm — — 1.66 kg
91201124 SPA112-04 112 mm 117.5 mm 8 2012 50 mm — 65 mm 78 mm 33 mm 32 mm — — 1.9 kg
91201184 SPA118-04 118 mm 123.5 mm 2 2012 50 mm — 65 mm 84 mm — 32 mm 33 mm — 2.22 kg
91201254 SPA125-04 125 mm 130.5 mm 2 2012 50 mm — 65 mm 91 mm — 32 mm 33 mm — 2.63 kg
91201324 SPA132-04 132 mm 137.5 mm 2 2517 60 mm — 65 mm 98 mm — 45 mm 20 mm — 2.79 kg
91201404 SPA140-04 140 mm 145.5 mm 2 2517 60 mm — 65 mm 106 mm — 45 mm 20 mm — 3.35 kg
91201504 SPA150-04 150 mm 155.5 mm 2 2517 60 mm — 65 mm 116 mm — 45 mm 20 mm — 4.05 kg
91201604 SPA160-04 160 mm 165.5 mm 2 2517 60 mm — 65 mm 125 mm — 45 mm 20 mm — 4.9 kg
91201704 SPA170-04 170 mm 175.5 mm 2 2517 60 mm — 65 mm 135 mm — 45 mm 20 mm — 5.75 kg
91201804 SPA180-04 180 mm 185.5 mm 2 2517 60 mm — 65 mm 146 mm — 45 mm 20 mm — 6.65 kg
91201904 SPA190-04 190 mm 195.5 mm 2 2517 60 mm — 65 mm 156 mm — 45 mm 20 mm — 7.55 kg
91202004 SPA200-04 200 mm 205.5 mm 2 3020 75 mm — 65 mm 165 mm — 51 mm 14 mm — 8.1 kg
91202124 SPA212-04 212 mm 217.5 mm 2 3020 75 mm — 65 mm 177 mm — 51 mm 14 mm — 9.55 kg
91202244 SPA224-04 224 mm 229.5 mm 2 3020 75 mm — 65 mm 189 mm — 51 mm 14 mm — 11.06 kg
91202364 SPA236-04 236 mm 241.5 mm 6 3020 75 mm 20 mm 56 mm 202 mm — 51 mm 14 mm 159 mm 9.85 kg
91202504 SPA250-04 250 mm 255.5 mm 5 3020 75 mm — 65 mm 215 mm 7 mm 51 mm 7 mm 159 mm 9.95 kg
91202804 SPA280-04 280 mm 285.5 mm 5 3020 75 mm — 65 mm 245 mm 7 mm 51 mm 7 mm 159 mm 11.4 kg
91203004 SPA300-04 300 mm 305.5 mm 5 3020 75 mm — 65 mm 265 mm 7 mm 51 mm 7 mm 159 mm 12.25 kg
91203154 SPA315-04 315 mm 320.5 mm 5 3020 75 mm — 65 mm 280 mm 7 mm 51 mm 7 mm 159 mm 12.95 kg
91203354 SPA335-04 335 mm 340.5 mm 5 3020 75 mm — 65 mm 300 mm 7 mm 51 mm 7 mm 159 mm 13.5 kg
91203554 SPA355-04 355 mm 360.5 mm 5 3020 75 mm — 65 mm 320 mm 7 mm 51 mm 7 mm 159 mm 14.48 kg
91204004 SPA400-04 400 mm 405.5 mm 5 3020 75 mm — 65 mm 365 mm 7 mm 51 mm 7 mm 159 mm 16.42 kg
91204504 SPA450-04 450 mm 455.5 mm 5 3020 75 mm — 65 mm 415 mm 7 mm 51 mm 7 mm 159 mm 19.45 kg
91205004 SPA500-04 500 mm 505.5 mm 5 3020 75 mm — 65 mm 465 mm 7 mm 51 mm 7 mm 159 mm 21.9 kg
91205604 SPA560-04 560 mm 565.5 mm 4 3535 90 mm — 65 mm 525 mm 12 mm 89 mm 12 mm 175 mm 28.5 kg
91206304 SPA630-04 630 mm 635.5 mm 4 3535 90 mm — 65 mm 595 mm 12 mm 89 mm 12 mm 175 mm 32.55 kg
91208004 SPA800-04 800 mm 805.5 mm 4 3535 90 mm — 65 mm 765 mm 12 mm 89 mm 12 mm 175 mm 45.05 kg

Product Information

Material
Cast iron
