Chiaravalli V-Belt Pulley for Taper Bushes SPB 3 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPB 3 Grooves

Cast-iron SPB V-belt pulley with 3 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91301063 SPB106-03 106 mm 113 mm 8 1610 42 mm — 63 mm 67 mm 38 mm 25 mm — — 1.8 kg
91301123 SPB112-03 112 mm 119 mm 8 1610 42 mm — 63 mm 72 mm 38 mm 25 mm — — 2.08 kg
91301183 SPB118-03 118 mm 125 mm 2 1610 42 mm — 63 mm 78 mm — 25 mm 38 mm — 2.35 kg
91301253 SPB125-03 125 mm 132 mm 2 2012 50 mm — 63 mm 82 mm — 32 mm 31 mm — 2.6 kg
91301323 SPB132-03 132 mm 139 mm 2 2012 50 mm — 63 mm 89 mm — 32 mm 31 mm — 3.0 kg
91301403 SPB140-03 140 mm 147 mm 2 2012 50 mm — 63 mm 97 mm — 32 mm 31 mm — 3.45 kg
91301503 SPB150-03 150 mm 157 mm 2 2517 60 mm — 63 mm 107 mm — 45 mm 18 mm — 3.9 kg
91301603 SPB160-03 160 mm 167 mm 2 2517 60 mm — 63 mm 117 mm — 45 mm 18 mm — 4.72 kg
91301703 SPB170-03 170 mm 177 mm 2 2517 60 mm — 63 mm 127 mm — 45 mm 18 mm — 5.55 kg
91301803 SPB180-03 180 mm 187 mm 2 2517 60 mm — 63 mm 137 mm — 45 mm 18 mm — 6.42 kg
91301903 SPB190-03 190 mm 197 mm 2 2517 60 mm — 63 mm 147 mm — 45 mm 18 mm — 7.37 kg
91302003 SPB200-03 200 mm 207 mm 2 2517 60 mm — 63 mm 157 mm — 45 mm 18 mm — 8.55 kg
91302123 SPB212-03 212 mm 219 mm 6 2517 60 mm 15 mm 63 mm 169 mm — 45 mm 18 mm 117 mm 7.37 kg
91302243 SPB224-03 224 mm 231 mm 5 2517 60 mm — 63 mm 181 mm — 45 mm 18 mm 117 mm 7.47 kg
91302363 SPB236-03 236 mm 243 mm 5 2517 60 mm — 63 mm 193 mm — 45 mm 18 mm 117 mm 7.95 kg
91302503 SPB250-03 250 mm 257 mm 5 3020 75 mm — 63 mm 207 mm — 51 mm 12 mm 144 mm 9.53 kg
91302803 SPB280-03 280 mm 287 mm 5 3020 75 mm — 63 mm 237 mm 6 mm 51 mm 6 mm 144 mm 10.86 kg
91303003 SPB300-03 300 mm 307 mm 5 3020 75 mm — 63 mm 257 mm 6 mm 51 mm 6 mm 144 mm 11.45 kg
91303153 SPB315-03 315 mm 322 mm 5 3020 75 mm — 63 mm 272 mm 6 mm 51 mm 6 mm 144 mm 12.25 kg
91303353 SPB335-03 335 mm 342 mm 5 3020 75 mm — 63 mm 292 mm 6 mm 51 mm 6 mm 144 mm 12.75 kg
91303553 SPB355-03 355 mm 362 mm 5 3020 75 mm — 63 mm 312 mm 6 mm 51 mm 6 mm 144 mm 14.85 kg
91304003 SPB400-03 400 mm 407 mm 4 3535 90 mm — 63 mm 357 mm 13 mm 89 mm 13 mm 175 mm 20.95 kg
91304503 SPB450-03 450 mm 457 mm 4 3535 90 mm — 63 mm 407 mm — 89 mm 26 mm 175 mm 24.5 kg
91305003 SPB500-03 500 mm 507 mm 4 3535 90 mm — 63 mm 457 mm — 89 mm 26 mm 175 mm 27.5 kg
91305603 SPB560-03 560 mm 567 mm 4 3535 90 mm — 63 mm 517 mm — 89 mm 26 mm 175 mm 29.32 kg
91306303 SPB630-03 630 mm 637 mm 4 3535 90 mm — 63 mm 587 mm — 89 mm 26 mm 175 mm 35.1 kg
91307103 SPB710-03 710 mm 717 mm 4 3535 90 mm — 63 mm 664 mm 13 mm 89 mm 13 mm 175 mm 42.3 kg
91308003 SPB800-03 800 mm 807 mm 4 3535 90 mm — 63 mm 754 mm 13 mm 89 mm 13 mm 175 mm 48.75 kg
91309003 SPB900-03 900 mm 907 mm 4 3535 90 mm — 63 mm 854 mm 13 mm 89 mm 13 mm 175 mm 55.5 kg
91310003 SPB1000-03 1000 mm 1007 mm 4 4040 100 mm — 63 mm 954 mm 19.5 mm 102 mm 19.5 mm 210 mm 76.4 kg
91312503 SPB1250-03 1250 mm 1257 mm 4 4040 100 mm — 63 mm 1204 mm 19.5 mm 102 mm 19.5 mm 210 mm 102.0 kg

Product Information

Material
Cast iron
