Chiaravalli V-Belt Pulley for Taper Bushes SPB 4 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPB 4 Grooves

Cast-iron SPB V-belt pulley with 4 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91301254 SPB125-04 125 mm 132 mm 3 2012 50 mm — 82 mm 82 mm 25 mm 32 mm 25 mm — 3.27 kg
91301324 SPB132-04 132 mm 139 mm 3 2012 50 mm — 82 mm 89 mm 25 mm 32 mm 25 mm — 3.65 kg
91301404 SPB140-04 140 mm 147 mm 3 2517 60 mm — 82 mm 100 mm 18.5 mm 45 mm 18.5 mm — 3.76 kg
91301504 SPB150-04 150 mm 157 mm 3 2517 60 mm — 82 mm 107 mm 18.5 mm 45 mm 18.5 mm — 4.7 kg
91301604 SPB160-04 160 mm 167 mm 3 2517 60 mm — 82 mm 117 mm 18.5 mm 45 mm 18.5 mm — 5.55 kg
91301704 SPB170-04 170 mm 177 mm 3 2517 60 mm — 82 mm 127 mm 18.5 mm 45 mm 18.5 mm — 6.48 kg
91301804 SPB180-04 180 mm 187 mm 3 2517 60 mm — 82 mm 137 mm 18.5 mm 45 mm 18.5 mm — 7.4 kg
91301904 SPB190-04 190 mm 197 mm 3 2517 60 mm — 82 mm 147 mm 18.5 mm 45 mm 18.5 mm — 8.4 kg
91302004 SPB200-04 200 mm 207 mm 3 3020 75 mm — 82 mm 157 mm 15.5 mm 51 mm 15.5 mm — 9.14 kg
91302124 SPB212-04 212 mm 219 mm 3 3020 75 mm — 82 mm 169 mm 15.5 mm 51 mm 15.5 mm — 10.6 kg
91302244 SPB224-04 224 mm 231 mm 3 3020 75 mm — 82 mm 181 mm 15.5 mm 51 mm 15.5 mm — 12.1 kg
91302364 SPB236-04 236 mm 243 mm 3 3020 75 mm — 82 mm 193 mm 15.5 mm 51 mm 15.5 mm — 13.8 kg
91302504 SPB250-04 250 mm 257 mm 5 3020 75 mm — 82 mm 207 mm 15.5 mm 51 mm 15.5 mm 144 mm 11.2 kg
91302804 SPB280-04 280 mm 287 mm 5 3020 75 mm — 82 mm 237 mm 15.5 mm 51 mm 15.5 mm 144 mm 12.95 kg
91303004 SPB300-04 300 mm 307 mm 4 3535 90 mm — 82 mm 257 mm — 89 mm 7 mm 175 mm 18.25 kg
91303154 SPB315-04 315 mm 322 mm 4 3535 90 mm — 82 mm 272 mm 3.5 mm 89 mm 3.5 mm 175 mm 19.25 kg
91303354 SPB335-04 335 mm 342 mm 4 3535 90 mm — 82 mm 292 mm 3.5 mm 89 mm 3.5 mm 175 mm 20.75 kg
91303554 SPB355-04 355 mm 362 mm 4 3535 90 mm — 82 mm 312 mm 3.5 mm 89 mm 3.5 mm 175 mm 21.62 kg
91303754 SPB375-04 375 mm 382 mm 4 3535 90 mm — 82 mm 332 mm 3.5 mm 89 mm 3.5 mm 175 mm 23.05 kg
91304004 SPB400-04 400 mm 407 mm 4 3535 90 mm — 82 mm 357 mm 3.5 mm 89 mm 3.5 mm 175 mm 24.76 kg
91304504 SPB450-04 450 mm 457 mm 4 3535 90 mm — 82 mm 407 mm — 89 mm 7 mm 175 mm 27.83 kg
91305004 SPB500-04 500 mm 507 mm 4 3535 90 mm — 82 mm 457 mm — 89 mm 7 mm 175 mm 30.84 kg
91305604 SPB560-04 560 mm 567 mm 4 3535 90 mm — 82 mm 517 mm — 89 mm 7 mm 175 mm 36.05 kg
91306304 SPB630-04 630 mm 637 mm 4 3535 90 mm — 82 mm 587 mm — 89 mm 7 mm 175 mm 40.12 kg
91307104 SPB710-04 710 mm 717 mm 4 3535 90 mm — 82 mm 664 mm 3.5 mm 89 mm 3.5 mm 175 mm 47.5 kg
91308004 SPB800-04 800 mm 807 mm 4 4040 100 mm — 82 mm 754 mm 10 mm 102 mm 10 mm 210 mm 63.4 kg
91309004 SPB900-04 900 mm 907 mm 4 4040 100 mm — 82 mm 854 mm 10 mm 102 mm 10 mm 210 mm 75.0 kg
91310004 SPB1000-04 1000 mm 1007 mm 4 4040 100 mm — 82 mm 954 mm 10 mm 102 mm 10 mm 210 mm 86.15 kg
91312504 SPB1250-04 1250 mm 1257 mm 4 4545 110 mm — 82 mm 1204 mm 16 mm 114 mm 16 mm 242 mm 116.0 kg

Product Information

Material
Cast iron
