Chiaravalli V-Belt Pulley for Taper Bushes SPB 5 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPB 5 Grooves

Cast-iron SPB V-belt pulley with 5 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91301255 SPB125-05 125 mm 132 mm 8 2012 50 mm — 101 mm 87 mm 69 mm 32 mm — — 3.55 kg
91301325 SPB132-05 132 mm 139 mm 8 2517 60 mm — 101 mm 94 mm 56 mm 45 mm — — 3.65 kg
91301405 SPB140-05 140 mm 147 mm 3 2517 60 mm — 101 mm 97 mm 28 mm 45 mm 28 mm — 4.6 kg
91301505 SPB150-05 150 mm 157 mm 3 2517 60 mm — 101 mm 107 mm 28 mm 45 mm 28 mm — 5.5 kg
91301605 SPB160-05 160 mm 167 mm 3 2517 60 mm — 101 mm 117 mm 28 mm 45 mm 28 mm — 6.45 kg
91301705 SPB170-05 170 mm 177 mm 3 3020 75 mm — 101 mm 127 mm 25 mm 51 mm 25 mm — 6.53 kg
91301805 SPB180-05 180 mm 187 mm 3 3020 75 mm — 101 mm 137 mm 25 mm 51 mm 25 mm — 7.55 kg
91301905 SPB190-05 190 mm 197 mm 3 3020 75 mm — 101 mm 147 mm 25 mm 51 mm 25 mm — 8.81 kg
91302005 SPB200-05 200 mm 207 mm 3 3020 75 mm — 101 mm 157 mm 25 mm 51 mm 25 mm — 10.25 kg
91302125 SPB212-05 212 mm 219 mm 3 3020 75 mm — 101 mm 169 mm 25 mm 51 mm 25 mm — 11.8 kg
91302245 SPB224-05 224 mm 231 mm 3 3020 75 mm — 101 mm 181 mm 25 mm 51 mm 25 mm — 13.5 kg
91302365 SPB236-05 236 mm 243 mm 3 3535 90 mm — 101 mm 193 mm 6 mm 89 mm 6 mm — 19.08 kg
91302505 SPB250-05 250 mm 257 mm 3 3535 90 mm — 101 mm 207 mm 6 mm 89 mm 6 mm — 20.32 kg
91302805 SPB280-05 280 mm 287 mm 6 3535 90 mm 25 mm 101 mm 237 mm 6 mm 89 mm 6 mm 175 mm 20.9 kg
91303005 SPB300-05 300 mm 307 mm 5 3535 90 mm — 101 mm 257 mm 6 mm 89 mm 6 mm 175 mm 19.45 kg
91303155 SPB315-05 315 mm 322 mm 5 3535 90 mm — 101 mm 272 mm 6 mm 89 mm 6 mm 175 mm 20.2 kg
91303355 SPB335-05 335 mm 342 mm 5 3535 90 mm — 101 mm 292 mm 6 mm 89 mm 6 mm 175 mm 22.7 kg
91303555 SPB355-05 355 mm 362 mm 5 3535 90 mm — 101 mm 312 mm 6 mm 89 mm 6 mm 175 mm 24.3 kg
91304005 SPB400-05 400 mm 407 mm 5 3535 90 mm — 101 mm 357 mm 6 mm 89 mm 6 mm 175 mm 27.78 kg
91304505 SPB450-05 450 mm 457 mm 5 3535 90 mm — 101 mm 407 mm — 89 mm 12 mm 175 mm 31.35 kg
91305005 SPB500-05 500 mm 507 mm 5 3535 90 mm — 101 mm 457 mm — 89 mm 12 mm 175 mm 35.15 kg
91305605 SPB560-05 560 mm 567 mm 4 4040 100 mm — 101 mm 517 mm — 102 mm 1 mm 210 mm 45.3 kg
91306305 SPB630-05 630 mm 637 mm 4 4040 100 mm — 101 mm 587 mm — 102 mm 1 mm 210 mm 50.15 kg
91307105 SPB710-05 710 mm 717 mm 4 4040 100 mm — 101 mm 664 mm — 102 mm 1 mm 210 mm 60.2 kg
91308005 SPB800-05 800 mm 807 mm 4 4040 100 mm — 101 mm 754 mm — 102 mm 1 mm 210 mm 68.0 kg
91310005 SPB1000-05 1000 mm 1007 mm 4 4545 110 mm — 101 mm 954 mm 6.5 mm 114 mm 6.5 mm 242 mm 99.75 kg
91312505 SPB1250-05 1250 mm 1257 mm 4 4545 110 mm — 101 mm 1204 mm 6.5 mm 114 mm 6.5 mm 242 mm 133.2 kg

Product Information

Material
Cast iron
