Chiaravalli V-Belt Pulley for Taper Bushes SPB 6 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPB 6 Grooves

Cast-iron SPB V-belt pulley with 6 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91301406 SPB140-06 140 mm 147 mm 3 2517 60 mm — 120 mm 100 mm 37.5 mm 45 mm 37.5 mm — 5.1 kg
91301506 SPB150-06 150 mm 157 mm 3 2517 60 mm — 120 mm 107 mm 37.5 mm 45 mm 37.5 mm — 6.25 kg
91301606 SPB160-06 160 mm 167 mm 3 3020 75 mm — 120 mm 119 mm 34.5 mm 51 mm 34.5 mm — 6.18 kg
91301706 SPB170-06 170 mm 177 mm 3 3020 75 mm — 120 mm 127 mm 34.5 mm 51 mm 34.5 mm — 7.35 kg
91301806 SPB180-06 180 mm 187 mm 3 3020 75 mm — 120 mm 137 mm 34.5 mm 51 mm 34.5 mm — 8.57 kg
91301906 SPB190-06 190 mm 197 mm 3 3020 75 mm — 120 mm 147 mm 34.5 mm 51 mm 34.5 mm — 9.75 kg
91302006 SPB200-06 200 mm 207 mm 3 3020 75 mm — 120 mm 157 mm 34.5 mm 51 mm 34.5 mm — 11.46 kg
91302126 SPB212-06 212 mm 219 mm 3 3535 90 mm — 120 mm 169 mm 15.5 mm 89 mm 15.5 mm — 14.95 kg
91302246 SPB224-06 224 mm 231 mm 3 3535 90 mm — 120 mm 181 mm 15.5 mm 89 mm 15.5 mm — 17.57 kg
91302366 SPB236-06 236 mm 243 mm 3 3535 90 mm — 120 mm 193 mm 15.5 mm 89 mm 15.5 mm — 20.25 kg
91302506 SPB250-06 250 mm 257 mm 3 3535 90 mm — 120 mm 207 mm 15.5 mm 89 mm 15.5 mm — 23.74 kg
91302806 SPB280-06 280 mm 287 mm 6 3535 90 mm 25 mm 120 mm 237 mm 15.5 mm 89 mm 15.5 mm 175 mm 22.52 kg
91303006 SPB300-06 300 mm 307 mm 5 3535 90 mm — 120 mm 257 mm 15.5 mm 89 mm 15.5 mm 175 mm 22.35 kg
91303156 SPB315-06 315 mm 322 mm 5 3535 90 mm — 120 mm 272 mm 15.5 mm 89 mm 15.5 mm 175 mm 23.55 kg
91303356 SPB335-06 335 mm 342 mm 5 3535 90 mm — 120 mm 292 mm 15.5 mm 89 mm 15.5 mm 175 mm 25.05 kg
91303556 SPB355-06 355 mm 362 mm 5 3535 90 mm — 120 mm 312 mm 15.5 mm 89 mm 15.5 mm 175 mm 26.08 kg
91304006 SPB400-06 400 mm 407 mm 5 3535 90 mm — 120 mm 357 mm 15.5 mm 89 mm 15.5 mm 175 mm 29.85 kg
91304506 SPB450-06 450 mm 457 mm 5 4040 100 mm — 120 mm 407 mm — 102 mm 18 mm 210 mm 39.3 kg
91305006 SPB500-06 500 mm 507 mm 5 4040 100 mm — 120 mm 457 mm — 102 mm 18 mm 210 mm 43.43 kg
91305606 SPB560-06 560 mm 567 mm 5 4040 100 mm — 120 mm 517 mm — 102 mm 18 mm 210 mm 48.55 kg
91306306 SPB630-06 630 mm 637 mm 5 4040 100 mm — 120 mm 587 mm — 102 mm 18 mm 210 mm 54.7 kg
91307106 SPB710-06 710 mm 717 mm 5 4040 100 mm — 120 mm 664 mm 9 mm 102 mm 9 mm 210 mm 65.98 kg
91308006 SPB800-06 800 mm 807 mm 5 4545 110 mm — 120 mm 754 mm 3 mm 114 mm 3 mm 242 mm 77.52 kg
91310006 SPB1000-06 1000 mm 1007 mm 5 4545 110 mm — 120 mm 954 mm 3 mm 114 mm 3 mm 242 mm 111.0 kg
91312506 SPB1250-06 1250 mm 1257 mm 5 4545 110 mm — 120 mm 1204 mm 3 mm 114 mm 3 mm 242 mm 144.0 kg

Product Information

Material
Cast iron
