Chiaravalli V-Belt Pulley for Taper Bushes SPB 8 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPB 8 Grooves

Cast-iron SPB V-belt pulley with 8 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91301408 SPB140-08 140 mm 147 mm 3 2517 60 mm — 158 mm 97 mm 56.5 mm 45 mm 56.5 mm — 6.78 kg
91301608 SPB160-08 160 mm 167 mm 3 3020 60 mm — 158 mm 118 mm 53.5 mm 51 mm 53.5 mm — 7.85 kg
91301808 SPB180-08 180 mm 187 mm 3 3030 75 mm — 158 mm 137 mm 41 mm 76 mm 41 mm — 12.0 kg
91301908 SPB190-08 190 mm 197 mm 3 3030 75 mm — 158 mm 147 mm 41 mm 76 mm 41 mm — 13.55 kg
91302008 SPB200-08 200 mm 207 mm 3 3535 75 mm — 158 mm 157 mm 34.5 mm 89 mm 34.5 mm — 14.6 kg
91302128 SPB212-08 212 mm 219 mm 3 3535 75 mm — 158 mm 169 mm 34.5 mm 89 mm 34.5 mm — 17.02 kg
91302248 SPB224-08 224 mm 231 mm 3 3535 75 mm — 158 mm 181 mm 34.5 mm 89 mm 34.5 mm — 20.16 kg
91302368 SPB236-08 236 mm 243 mm 3 3535 90 mm — 158 mm 193 mm 34.5 mm 89 mm 34.5 mm — 22.9 kg
91302508 SPB250-08 250 mm 257 mm 3 3535 90 mm — 158 mm 207 mm 34.5 mm 89 mm 34.5 mm — 26.69 kg
91302808 SPB280-08 280 mm 287 mm 6 3535 90 mm 25 mm 158 mm 237 mm 34.5 mm 89 mm 34.5 mm 175 mm 25.87 kg
91303008 SPB300-08 300 mm 307 mm 6 3535 90 mm 25 mm 158 mm 257 mm 34.5 mm 89 mm 34.5 mm 175 mm 28.55 kg
91303158 SPB315-08 315 mm 322 mm 5 3535 90 mm — 158 mm 272 mm 34.5 mm 89 mm 34.5 mm 175 mm 28.35 kg
91303358 SPB335-08 335 mm 342 mm 5 3535 90 mm — 158 mm 292 mm 34.5 mm 89 mm 34.5 mm 175 mm 31.1 kg
91303558 SPB355-08 355 mm 362 mm 5 3535 90 mm — 158 mm 312 mm 34.5 mm 89 mm 34.5 mm 175 mm 31.4 kg
91304008 SPB400-08 400 mm 407 mm 5 4040 100 mm — 158 mm 357 mm 28 mm 102 mm 28 mm 210 mm 41.5 kg
91304508 SPB450-08 450 mm 457 mm 5 4040 100 mm — 158 mm 407 mm 28 mm 102 mm 28 mm 210 mm 46.75 kg
91305008 SPB500-08 500 mm 507 mm 5 4040 100 mm — 158 mm 457 mm 28 mm 102 mm 28 mm 210 mm 52.35 kg
91305608 SPB560-08 560 mm 567 mm 5 4545 110 mm — 158 mm 517 mm 22 mm 114 mm 22 mm 242 mm 65.7 kg
91306308 SPB630-08 630 mm 637 mm 5 4545 110 mm — 158 mm 587 mm 22 mm 114 mm 22 mm 242 mm 72.06 kg
91307108 SPB710-08 710 mm 717 mm 5 4545 110 mm — 158 mm 664 mm 22 mm 114 mm 22 mm 242 mm 83.0 kg
91308008 SPB800-08 800 mm 807 mm 5 4545 110 mm — 158 mm 754 mm 22 mm 114 mm 22 mm 242 mm 97.56 kg
91310008 SPB1000-08 1000 mm 1007 mm 5 5050 125 mm — 158 mm 954 mm 15.5 mm 127 mm 15.5 mm 267 mm 130.0 kg
91312508 SPB1250-08 1250 mm 1257 mm 5 5050 125 mm — 158 mm 1204 mm 15.5 mm 127 mm 15.5 mm 267 mm 161.4 kg

Product Information

Material
Cast iron
