Chiaravalli V-Belt Pulley for Taper Bushes SPC 10 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPC 10 Grooves

Cast-iron SPC V-belt pulley with 10 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91402210 SPC224-10 224 mm 233.6 mm 3 4040 100 mm — 264 mm 168 mm 81 mm 102 mm 81 mm — 27.0 kg
91402510 SPC250-10 250 mm 259.6 mm 3 4040 100 mm — 264 mm 194 mm 81 mm 102 mm 81 mm — 35.35 kg
91402810 SPC280-10 280 mm 289.6 mm 3 4040 100 mm — 264 mm 224 mm 81 mm 102 mm 81 mm — 45.92 kg
91403010 SPC300-10 300 mm 309.6 mm 3 4545 110 mm — 264 mm 244 mm 75 mm 114 mm 75 mm — 54.0 kg
91403110 SPC315-10 315 mm 324.6 mm 3 4545 110 mm — 264 mm 259 mm 75 mm 114 mm 75 mm — 59.7 kg
91403310 SPC335-10 335 mm 344.6 mm 3 4545 110 mm — 264 mm 279 mm 75 mm 114 mm 75 mm — 71.0 kg
91403510 SPC355-10 355 mm 364.6 mm 3 4545 110 mm — 264 mm 299 mm 75 mm 114 mm 75 mm — 80.5 kg
91404010 SPC400-10 400 mm 409.6 mm 6 5050 125 mm 70 mm 264 mm 344 mm 68.5 mm 127 mm 68.5 mm 267 mm 92.0 kg
91404510 SPC450-10 450 mm 459.6 mm 5 5050 125 mm — 264 mm 394 mm 68.5 mm 127 mm 68.5 mm 267 mm 89.4 kg
91405010 SPC500-10 500 mm 509.6 mm 5 5050 125 mm — 264 mm 444 mm 68.5 mm 127 mm 68.5 mm 267 mm 100.0 kg
91405610 SPC560-10 560 mm 569.6 mm 5 5050 125 mm — 264 mm 504 mm 68.5 mm 127 mm 68.5 mm 267 mm 114.0 kg
91406310 SPC630-10 630 mm 639.6 mm 5 5050 125 mm — 264 mm 574 mm 68.5 mm 127 mm 68.5 mm 267 mm 128.0 kg
91407110 SPC710-10 710 mm 719.6 mm 5 5050 125 mm — 264 mm 654 mm 68.5 mm 127 mm 68.5 mm 267 mm 148.0 kg
91408010 SPC800-10 800 mm 809.6 mm 5 5050 125 mm — 264 mm 737 mm 68.5 mm 127 mm 68.5 mm 267 mm 174.0 kg
91410010 SPC1000-10 1000 mm 1009.6 mm 5 5050 125 mm — 264 mm 937 mm 68.5 mm 127 mm 68.5 mm 267 mm 222.0 kg
91412510 SPC1250-10 1250 mm 1259.6 mm 5 5050 125 mm — 264 mm 1187 mm 68.5 mm 127 mm 68.5 mm 267 mm 311.0 kg

Product Information

Material
Cast iron
