Chiaravalli V-Belt Pulley for Taper Bushes SPC 3 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPC 3 Grooves

Cast-iron SPC V-belt pulley with 3 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91401803 SPC180-03 180 mm 189.6 mm 3 2517 60 mm — 85 mm 124 mm 20 mm 45 mm 20 mm — 7.94 kg
91402003 SPC200-03 200 mm 209.6 mm 3 2517 60 mm — 85 mm 144 mm 20 mm 45 mm 20 mm — 10.06 kg
91402243 SPC224-03 224 mm 233.6 mm 3 3020 75 mm — 85 mm 168 mm 17 mm 51 mm 17 mm — 12.35 kg
91402503 SPC250-03 250 mm 259.6 mm 3 3020 75 mm — 85 mm 194 mm 17 mm 51 mm 17 mm — 16.15 kg
91402803 SPC280-03 280 mm 289.6 mm 1 3535 90 mm — 85 mm — — 89 mm 4 mm 175 mm 27.05 kg
91403003 SPC300-03 300 mm 309.6 mm 4 3535 90 mm — 85 mm 244 mm 2 mm 89 mm 2 mm 175 mm 20.63 kg
91403153 SPC315-03 315 mm 324.6 mm 4 3535 90 mm — 85 mm 259 mm 2 mm 89 mm 2 mm 175 mm 21.91 kg
91403353 SPC335-03 335 mm 344.6 mm 4 3535 90 mm — 85 mm 279 mm 2 mm 89 mm 2 mm 175 mm 23.65 kg
91403553 SPC355-03 355 mm 364.6 mm 4 3535 90 mm — 85 mm 299 mm 2 mm 89 mm 2 mm 175 mm 24.2 kg
91404003 SPC400-03 400 mm 409.6 mm 4 3535 90 mm — 85 mm 344 mm 2 mm 89 mm 2 mm 175 mm 27.63 kg
91404503 SPC450-03 450 mm 459.6 mm 4 3535 90 mm — 85 mm 394 mm 2 mm 89 mm 2 mm 175 mm 31.6 kg
91405003 SPC500-03 500 mm 509.6 mm 4 3535 90 mm — 85 mm 444 mm 2 mm 89 mm 2 mm 175 mm 36.3 kg
91405603 SPC560-03 560 mm 569.6 mm 4 3535 90 mm — 85 mm 504 mm 2 mm 89 mm 2 mm 175 mm 40.12 kg
91406303 SPC630-03 630 mm 639.6 mm 4 4040 100 mm — 85 mm 574 mm 8.5 mm 102 mm 8.5 mm 210 mm 51.45 kg
91408003 SPC800-03 800 mm 809.6 mm 4 4545 110 mm — 85 mm 737 mm 14.5 mm 114 mm 14.5 mm 242 mm 79.0 kg
91410003 SPC1000-03 1000 mm 1009.6 mm 4 5050 125 mm — 85 mm 937 mm 21 mm 127 mm 21 mm 267 mm 120.5 kg
91412503 SPC1250-03 1250 mm 1259.6 mm 4 5050 125 mm — 85 mm 1187 mm 21 mm 127 mm 21 mm 267 mm 136.0 kg

Product Information

Material
Cast iron
