Chiaravalli V-Belt Pulley for Taper Bushes SPC 4 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPC 4 Grooves

Cast-iron SPC V-belt pulley with 4 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91401804 SPC180-04 180 mm 189.6 mm 3 3020 75 mm — 111 mm 124 mm 30 mm 51 mm 30 mm — 8.65 kg
91402004 SPC200-04 200 mm 209.6 mm 3 3020 75 mm — 111 mm 144 mm 30 mm 51 mm 30 mm — 11.15 kg
91402244 SPC224-04 224 mm 233.6 mm 3 3535 90 mm — 111 mm 168 mm 11 mm 89 mm 11 mm — 16.3 kg
91402504 SPC250-04 250 mm 259.6 mm 3 3535 90 mm — 111 mm 194 mm 11 mm 89 mm 11 mm — 22.0 kg
91402804 SPC280-04 280 mm 289.6 mm 6 3535 90 mm 18 mm 111 mm 224 mm 11 mm 89 mm 11 mm 175 mm 22.51 kg
91403004 SPC300-04 300 mm 309.6 mm 6 3535 90 mm 20 mm 111 mm 244 mm 11 mm 89 mm 11 mm 175 mm 24.6 kg
91403154 SPC315-04 315 mm 324.6 mm 5 3535 90 mm — 111 mm 259 mm 11 mm 89 mm 11 mm 175 mm 24.73 kg
91403354 SPC335-04 335 mm 344.6 mm 5 3535 90 mm — 111 mm 279 mm 11 mm 89 mm 11 mm 175 mm 27.45 kg
91403554 SPC355-04 355 mm 364.6 mm 5 3535 90 mm — 111 mm 299 mm 11 mm 89 mm 11 mm 175 mm 29.5 kg
91404004 SPC400-04 400 mm 409.6 mm 5 3535 90 mm — 111 mm 344 mm 11 mm 89 mm 11 mm 175 mm 33.27 kg
91404504 SPC450-04 450 mm 459.6 mm 5 3535 90 mm — 111 mm 394 mm 11 mm 89 mm 11 mm 175 mm 36.8 kg
91405004 SPC500-04 500 mm 509.6 mm 5 3535 90 mm — 111 mm 444 mm 11 mm 89 mm 11 mm 175 mm 42.6 kg
91405604 SPC560-04 560 mm 569.6 mm 5 4040 100 mm — 111 mm 504 mm 4.5 mm 102 mm 4.5 mm 210 mm 53.15 kg
91406304 SPC630-04 630 mm 639.6 mm 4 4545 110 mm — 111 mm 574 mm 1.5 mm 114 mm 1.5 mm 242 mm 68.2 kg
91407104 SPC710-04 710 mm 719.6 mm 4 5050 125 mm — 111 mm 654 mm 8 mm 127 mm 8 mm 267 mm 86.16 kg
91408004 SPC800-04 800 mm 809.6 mm 4 5050 125 mm — 111 mm 737 mm 8 mm 127 mm 8 mm 267 mm 97.15 kg
91410004 SPC1000-04 1000 mm 1009.6 mm 4 5050 125 mm — 111 mm 937 mm 8 mm 127 mm 8 mm 267 mm 125.0 kg
91412504 SPC1250-04 1250 mm 1259.6 mm 4 5050 125 mm — 111 mm 1187 mm 8 mm 127 mm 8 mm 267 mm 166.0 kg

Product Information

Material
Cast iron
