Chiaravalli V-Belt Pulley for Taper Bushes SPC 5 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPC 5 Grooves

Cast-iron SPC V-belt pulley with 5 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91401805 SPC180-05 180 mm 189.6 mm 3 3020 75 mm — 136 mm 124 mm 42.5 mm 51 mm 42.5 mm — 9.2 kg
91402005 SPC200-05 200 mm 209.6 mm 3 3535 90 mm — 136 mm 144 mm 23.5 mm 89 mm 23.5 mm — 13.07 kg
91402245 SPC224-05 224 mm 233.6 mm 3 3535 90 mm — 136 mm 168 mm 23.5 mm 89 mm 23.5 mm — 18.3 kg
91402505 SPC250-05 250 mm 259.6 mm 3 3535 90 mm — 136 mm 194 mm 23.5 mm 89 mm 23.5 mm — 24.55 kg
91402805 SPC280-05 280 mm 289.6 mm 3 3535 90 mm — 136 mm 224 mm 23.5 mm 89 mm 23.5 mm — 32.81 kg
91403005 SPC300-05 300 mm 309.6 mm 6 3535 90 mm 20 mm 136 mm 244 mm 23.5 mm 89 mm 23.5 mm 175 mm 29.8 kg
91403155 SPC315-05 315 mm 324.6 mm 5 3535 90 mm — 136 mm 259 mm 23.5 mm 89 mm 23.5 mm 210 mm 28.21 kg
91403355 SPC335-05 335 mm 344.6 mm 5 3535 90 mm — 136 mm 279 mm 23.5 mm 89 mm 23.5 mm 210 mm 30.7 kg
91403555 SPC355-05 355 mm 364.6 mm 5 3535 90 mm — 136 mm 299 mm 23.5 mm 89 mm 23.5 mm 242 mm 33.12 kg
91404005 SPC400-05 400 mm 409.6 mm 5 3535 90 mm — 136 mm 344 mm 23.5 mm 89 mm 23.5 mm 267 mm 37.4 kg
91404505 SPC450-05 450 mm 459.6 mm 5 4040 100 mm — 136 mm 394 mm 17 mm 102 mm 17 mm 267 mm 48.1 kg
91405005 SPC500-05 500 mm 509.6 mm 5 4040 100 mm — 136 mm 444 mm 17 mm 102 mm 17 mm 267 mm 54.0 kg
91405605 SPC560-05 560 mm 569.6 mm 5 4545 110 mm — 136 mm 504 mm 11 mm 114 mm 11 mm 267 mm 66.77 kg
91406305 SPC630-05 630 mm 639.6 mm 5 5050 125 mm — 136 mm 574 mm 4.5 mm 127 mm 4.5 mm 267 mm 82.0 kg
91407105 SPC710-05 710 mm 719.6 mm 5 5050 125 mm — 136 mm 654 mm 4.5 mm 127 mm 4.5 mm 267 mm 93.2 kg
91408005 SPC800-05 800 mm 809.6 mm 5 5050 125 mm — 136 mm 737 mm 4.5 mm 127 mm 4.5 mm 267 mm 110.0 kg
91410005 SPC1000-05 1000 mm 1009.6 mm 5 5050 125 mm — 136 mm 937 mm 4.5 mm 127 mm 4.5 mm 267 mm 154.0 kg
91412505 SPC1250-05 1250 mm 1259.6 mm 5 5050 125 mm — 136 mm 1187 mm 4.5 mm 127 mm 4.5 mm 267 mm 188.0 kg

Product Information

Material
Cast iron
