Chiaravalli V-Belt Pulley for Taper Bushes SPC 6 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPC 6 Grooves

Cast-iron SPC V-belt pulley with 6 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91401806 SPC180-06 180 mm 189.6 mm 3 3020 75 mm — 162 mm 124 mm 55.5 mm 51 mm 55.5 mm — 11.88 kg —
91402006 SPC200-06 200 mm 209.6 mm 3 3535 90 mm — 162 mm 144 mm 36.5 mm 89 mm 36.5 mm — 14.8 kg
91402246 SPC224-06 224 mm 233.6 mm 3 3535 90 mm — 162 mm 168 mm 36.5 mm 89 mm 36.5 mm — 20.3 kg
91402366 SPC236-06 236 mm 245.6 mm 3 3535 90 mm — 162 mm 180 mm 36.5 mm 89 mm 36.5 mm — 23.31 kg —
91402506 SPC250-06 250 mm 259.6 mm 3 3535 90 mm — 162 mm 194 mm 36.5 mm 89 mm 36.5 mm — 27.17 kg
91402806 SPC280-06 280 mm 289.6 mm 6 3535 90 mm 20 mm 162 mm 224 mm 36.5 mm 89 mm 36.5 mm 175 mm 28.9 kg
91403006 SPC300-06 300 mm 309.6 mm 6 3535 90 mm 20 mm 162 mm 244 mm 36.5 mm 89 mm 36.5 mm 175 mm 30.35 kg
91403156 SPC315-06 315 mm 324.6 mm 5 3535 90 mm — 162 mm 259 mm 36.5 mm 89 mm 36.5 mm 175 mm 31.35 kg
91403356 SPC335-06 335 mm 344.6 mm 5 3535 90 mm — 162 mm 279 mm 36.5 mm 89 mm 36.5 mm 175 mm 35.0 kg
91403556 SPC355-06 355 mm 364.6 mm 5 3535 90 mm — 162 mm 299 mm 36.5 mm 89 mm 36.5 mm 175 mm 37.1 kg
91404006 SPC400-06 400 mm 409.6 mm 5 4040 100 mm — 162 mm 344 mm 30 mm 102 mm 30 mm 210 mm 47.76 kg
91404506 SPC450-06 450 mm 459.6 mm 5 4545 110 mm — 162 mm 394 mm 24 mm 114 mm 24 mm 242 mm 60.98 kg
91405006 SPC500-06 500 mm 509.6 mm 5 4545 110 mm — 162 mm 444 mm 24 mm 114 mm 24 mm 242 mm 67.6 kg
91405606 SPC560-06 560 mm 569.6 mm 5 5050 125 mm — 162 mm 504 mm 17.5 mm 127 mm 17.5 mm 267 mm 81.4 kg
91406306 SPC630-06 630 mm 639.6 mm 5 5050 125 mm — 162 mm 574 mm 17.5 mm 127 mm 17.5 mm 267 mm 89.7 kg
91407106 SPC710-06 710 mm 719.6 mm 5 5050 125 mm — 162 mm 654 mm 17.5 mm 127 mm 17.5 mm 267 mm 102.6 kg
91408006 SPC800-06 800 mm 809.6 mm 5 5050 125 mm — 162 mm 737 mm 17.5 mm 127 mm 17.5 mm 267 mm 123.6 kg
91410006 SPC1000-06 1000 mm 1009.6 mm 5 5050 125 mm — 162 mm 937 mm 17.5 mm 127 mm 17.5 mm 267 mm 160.0 kg
91412506 SPC1250-06 1250 mm 1259.6 mm 5 5050 125 mm — 162 mm 1187 mm 17.5 mm 127 mm 17.5 mm 267 mm 201.0 kg

Product Information

Material
Cast iron
