Chiaravalli V-Belt Pulley for Taper Bushes SPC 8 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPC 8 Grooves

Cast-iron SPC V-belt pulley with 8 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91402008 SPC200-08 200 mm 209.6 mm 3 3535 90 mm — 213 mm 144 mm 62 mm 89 mm 62 mm — 18.52 kg
91402248 SPC224-08 224 mm 233.6 mm 3 3535 90 mm — 213 mm 168 mm 62 mm 89 mm 62 mm — 24.85 kg
91402508 SPC250-08 250 mm 259.6 mm 3 3535 90 mm — 213 mm 194 mm 62 mm 89 mm 62 mm — 31.9 kg
91402808 SPC280-08 280 mm 289.6 mm 3 3535 90 mm — 213 mm 224 mm 62 mm 89 mm 62 mm — 40.6 kg
91403008 SPC300-08 300 mm 309.6 mm 3 4040 100 mm — 213 mm 244 mm 55.5 mm 102 mm 55.5 mm — 47.71 kg
91403158 SPC315-08 315 mm 324.6 mm 3 4040 100 mm — 213 mm 259 mm 55.5 mm 102 mm 55.5 mm — 53.92 kg
91403358 SPC335-08 335 mm 344.6 mm 6 4040 100 mm 50 mm 213 mm 279 mm 55.5 mm 102 mm 55.5 mm 210 mm 53.0 kg
91403558 SPC355-08 355 mm 364.6 mm 5 4040 100 mm — 213 mm 299 mm 55.5 mm 102 mm 55.5 mm 210 mm 50.67 kg
91404008 SPC400-08 400 mm 409.6 mm 5 4545 110 mm — 213 mm 344 mm 49.5 mm 114 mm 49.5 mm 242 mm 65.1 kg
91404508 SPC450-08 450 mm 459.6 mm 5 5050 125 mm — 213 mm 394 mm 43 mm 127 mm 43 mm 267 mm 77.33 kg
91405008 SPC500-08 500 mm 509.6 mm 5 5050 125 mm — 213 mm 444 mm 43 mm 127 mm 43 mm 267 mm 88.7 kg
91405608 SPC560-08 560 mm 569.6 mm 5 5050 125 mm — 213 mm 504 mm 43 mm 127 mm 43 mm 267 mm 95.8 kg
91406308 SPC630-08 630 mm 639.6 mm 5 5050 125 mm — 213 mm 574 mm 43 mm 127 mm 43 mm 267 mm 106.0 kg
91407108 SPC710-08 710 mm 719.6 mm 5 5050 125 mm — 213 mm 654 mm 43 mm 127 mm 43 mm 267 mm 124.0 kg
91408008 SPC800-08 800 mm 809.6 mm 5 5050 125 mm — 213 mm 737 mm 43 mm 127 mm 43 mm 267 mm 150.0 kg
91410008 SPC1000-08 1000 mm 1009.6 mm 5 5050 125 mm — 213 mm 937 mm 43 mm 127 mm 43 mm 267 mm 191.0 kg
91412508 SPC1250-08 1250 mm 1259.6 mm 5 5050 125 mm — 213 mm 1187 mm 43 mm 127 mm 43 mm 267 mm 255.0 kg

Product Information

Material
Cast iron
