Chiaravalli V-Belt Pulley for Taper Bushes SPZ 1 Groove — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPZ 1 Groove

Cast-iron SPZ V-belt pulley with 1 groove, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91100601 SPZ60-01 60 mm 64 mm 1 1008 25 mm — 22 mm — — 22 mm — — 0.3 kg
91100631 SPZ63-01 63 mm 67 mm 1 1108 28 mm — 16 mm — — 22 mm 6 mm 56 mm 0.23 kg
91100671 SPZ67-01 67 mm 71 mm 1 1108 28 mm — 16 mm — — 22 mm 6 mm 60 mm 0.3 kg
91100711 SPZ71-01 71 mm 75 mm 1 1108 28 mm — 16 mm — — 22 mm 6 mm 60 mm 0.35 kg
91100751 SPZ75-01 75 mm 79 mm 1 1108 28 mm — 16 mm — — 22 mm 6 mm 60 mm 0.4 kg
91100801 SPZ80-01 80 mm 84 mm 1 1210 32 mm — 16 mm — — 25 mm 9 mm 75 mm 0.49 kg
91100851 SPZ85-01 85 mm 89 mm 1 1210 32 mm — 16 mm — — 25 mm 9 mm 80 mm 0.6 kg
91100901 SPZ90-01 90 mm 94 mm 1 1210 32 mm — 16 mm — — 25 mm 9 mm 80 mm 0.7 kg
91100951 SPZ95-01 95 mm 99 mm 1 1210 32 mm — 16 mm — — 25 mm 9 mm 85 mm 0.8 kg
91101001 SPZ100-01 100 mm 104 mm 1 1210 32 mm — 16 mm — — 25 mm 9 mm 85 mm 0.9 kg
91101061 SPZ106-01 106 mm 110 mm 1 1610 42 mm — 16 mm — — 25 mm 9 mm 92 mm 0.92 kg
91101121 SPZ112-01 112 mm 116 mm 1 1610 42 mm — 16 mm — — 25 mm 9 mm 92 mm 1.03 kg
91101181 SPZ118-01 118 mm 122 mm 1 1610 42 mm — 16 mm — — 25 mm 9 mm 92 mm 1.16 kg
91101251 SPZ125-01 125 mm 129 mm 1 1610 42 mm — 16 mm — — 25 mm 9 mm 92 mm 1.3 kg
91101321 SPZ132-01 132 mm 136 mm 1 1610 42 mm — 16 mm — — 25 mm 9 mm 92 mm 1.45 kg
91101401 SPZ140-01 140 mm 144 mm 1 1610 42 mm — 16 mm — — 25 mm 9 mm 92 mm 1.65 kg
91101501 SPZ150-01 150 mm 154 mm 1 1610 42 mm — 16 mm — — 25 mm 9 mm 92 mm 1.92 kg
91101601 SPZ160-01 160 mm 164 mm 1 1610 42 mm — 16 mm — — 25 mm 9 mm 92 mm 2.17 kg
91101801 SPZ180-01 180 mm 184 mm 4 1610 42 mm — 16 mm 152 mm — 25 mm 9 mm 92 mm 1.9 kg
91102001 SPZ200-01 200 mm 204 mm 4 2012 50 mm — 16 mm 171 mm — 32 mm 16 mm 112 mm 2.25 kg
91102241 SPZ224-01 224 mm 228 mm 4 2012 50 mm — 16 mm 195 mm — 32 mm 16 mm 112 mm 2.93 kg
91102501 SPZ250-01 250 mm 254 mm 4 2012 50 mm — 16 mm 221 mm 8 mm 32 mm 8 mm 112 mm 3.37 kg
91102801 SPZ280-01 280 mm 284 mm 4 2012 50 mm — 16 mm 251 mm 8 mm 32 mm 8 mm 112 mm 3.7 kg
91103151 SPZ315-01 315 mm 319 mm 4 2012 50 mm — 16 mm 286 mm 8 mm 32 mm 8 mm 112 mm 4.32 kg
91103551 SPZ355-01 355 mm 359 mm 4 2012 50 mm — 16 mm 326 mm 8 mm 32 mm 8 mm 112 mm 5.1 kg
91104001 SPZ400-01 400 mm 404 mm 4 2012 50 mm — 16 mm 371 mm 8 mm 32 mm 8 mm 112 mm 5.99 kg
91104501 SPZ450-01 450 mm 454 mm 4 2517 60 mm — 16 mm 421 mm 14.5 mm 45 mm 14.5 mm 124 mm 7.19 kg
91105001 SPZ500-01 500 mm 504 mm 4 2517 60 mm — 16 mm 471 mm 14.5 mm 45 mm 14.5 mm 124 mm 8.5 kg —

Product Information

Material
Cast iron
