Chiaravalli V-Belt Pulley for Taper Bushes SPZ 2 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPZ 2 Grooves

Cast-iron SPZ V-belt pulley with 2 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91100602 SPZ60-02 60 mm 64 mm 9 1108 28 mm — 49 mm 36 mm 27 mm 22 mm — — 0.6 kg
91100632 SPZ63-02 63 mm 67 mm 8 1108 28 mm — 28 mm 40 mm 6 mm 22 mm — — 0.3 kg
91100672 SPZ67-02 67 mm 71 mm 8 1108 28 mm — 28 mm 42 mm 6 mm 22 mm — — 0.36 kg
91100712 SPZ71-02 71 mm 75 mm 8 1108 28 mm — 28 mm 42 mm 6 mm 22 mm — — 0.45 kg
91100752 SPZ75-02 75 mm 79 mm 8 1210 32 mm — 28 mm 51 mm 3 mm 25 mm — — 0.41 kg
91100802 SPZ80-02 80 mm 84 mm 8 1210 32 mm — 28 mm 51 mm 3 mm 25 mm — — 0.52 kg
91100852 SPZ85-02 85 mm 89 mm 8 1610 42 mm — 28 mm 60 mm 3 mm 25 mm — — 0.5 kg
91100902 SPZ90-02 90 mm 94 mm 8 1610 42 mm — 28 mm 61 mm 3 mm 25 mm — — 0.63 kg
91100952 SPZ95-02 95 mm 99 mm 8 1610 42 mm — 28 mm 66 mm 3 mm 25 mm — — 0.74 kg
91101002 SPZ100-02 100 mm 104 mm 8 1610 42 mm — 28 mm 71 mm 3 mm 25 mm — — 0.9 kg
91101062 SPZ106-02 106 mm 110 mm 8 1610 42 mm — 28 mm 76 mm 3 mm 25 mm — — 1.05 kg
91101122 SPZ112-02 112 mm 116 mm 8 1610 42 mm — 28 mm 83 mm 3 mm 25 mm — — 1.25 kg
91101182 SPZ118-02 118 mm 122 mm 8 1610 42 mm — 28 mm 90 mm 3 mm 25 mm — — 1.45 kg
91101252 SPZ125-02 125 mm 129 mm 8 1610 42 mm — 28 mm 96 mm 3 mm 25 mm — — 1.65 kg
91101322 SPZ132-02 132 mm 136 mm 8 1610 42 mm — 28 mm 103 mm 3 mm 25 mm — — 1.9 kg
91101402 SPZ140-02 140 mm 144 mm 8 1610 42 mm — 28 mm 111 mm 3 mm 25 mm — — 2.22 kg
91101502 SPZ150-02 150 mm 154 mm 1 2012 50 mm — 28 mm — — 32 mm 4 mm 112 mm 2.74 kg
91101602 SPZ160-02 160 mm 164 mm 1 2012 50 mm — 28 mm — — 32 mm 4 mm 112 mm 3.23 kg
91101802 SPZ180-02 180 mm 184 mm 7 2012 50 mm 10 mm 28 mm 152 mm — 32 mm 4 mm 112 mm 3.18 kg
91101902 SPZ190-02 190 mm 194 mm 7 2012 50 mm 10 mm 28 mm 162 mm — 32 mm 4 mm 112 mm 3.45 kg
91102002 SPZ200-02 200 mm 204 mm 4 2012 50 mm — 28 mm 171 mm — 32 mm 4 mm 112 mm 4.2 kg
91102242 SPZ224-02 224 mm 228 mm 4 2012 50 mm — 28 mm 195 mm — 32 mm 4 mm 112 mm 3.86 kg
91102502 SPZ250-02 250 mm 254 mm 4 2012 50 mm — 28 mm 221 mm 2 mm 32 mm 2 mm 112 mm 4.22 kg
91102802 SPZ280-02 280 mm 284 mm 4 2012 50 mm — 28 mm 251 mm 2 mm 32 mm 2 mm 112 mm 4.85 kg
91103152 SPZ315-02 315 mm 319 mm 4 2012 50 mm — 28 mm 286 mm 2 mm 32 mm 2 mm 112 mm 5.49 kg
91103552 SPZ355-02 355 mm 359 mm 4 2012 50 mm — 28 mm 326 mm 2 mm 32 mm 2 mm 112 mm 6.19 kg
91104002 SPZ400-02 400 mm 404 mm 4 2517 60 mm — 28 mm 371 mm 8.5 mm 45 mm 8.5 mm 124 mm 8.95 kg
91104502 SPZ450-02 450 mm 454 mm 4 2517 60 mm — 28 mm 421 mm 8.5 mm 45 mm 8.5 mm 124 mm 9.9 kg
91105002 SPZ500-02 500 mm 504 mm 4 2517 60 mm — 28 mm 471 mm 8.5 mm 45 mm 8.5 mm 124 mm 10.25 kg

Product Information

Material
Cast iron
