Chiaravalli V-Belt Pulley for Taper Bushes SPZ 4 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPZ 4 Grooves

Cast-iron SPZ V-belt pulley with 4 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91100804 SPZ80-04 80 mm 84 mm 8 1210 32 mm — 52 mm 51 mm 27 mm 25 mm — — 0.87 kg
91100854 SPZ85-04 85 mm 89 mm 8 1610 42 mm — 52 mm 60 mm 27 mm 25 mm — — 0.84 kg
91100904 SPZ90-04 90 mm 94 mm 8 1610 42 mm — 52 mm 61 mm 27 mm 25 mm — — 1.08 kg
91100954 SPZ95-04 95 mm 99 mm 8 1610 42 mm — 52 mm 66 mm 27 mm 25 mm — — 1.21 kg
91101004 SPZ100-04 100 mm 104 mm 8 1610 42 mm — 52 mm 71 mm 27 mm 25 mm — — 1.38 kg
91101064 SPZ106-04 106 mm 110 mm 8 1610 42 mm — 52 mm 76 mm 27 mm 25 mm — — 1.6 kg
91101124 SPZ112-04 112 mm 116 mm 8 2012 50 mm — 52 mm 83 mm 20 mm 32 mm — — 1.65 kg
91101184 SPZ118-04 118 mm 122 mm 8 2012 50 mm — 52 mm 90 mm 20 mm 32 mm — — 1.97 kg
91101254 SPZ125-04 125 mm 129 mm 2 2012 50 mm — 52 mm 96 mm — 32 mm 20 mm — 2.24 kg
91101324 SPZ132-04 132 mm 136 mm 2 2012 50 mm — 52 mm 103 mm — 32 mm 20 mm — 2.6 kg
91101404 SPZ140-04 140 mm 144 mm 2 2012 50 mm — 52 mm 111 mm — 32 mm 20 mm — 3.0 kg
91101504 SPZ150-04 150 mm 154 mm 2 2517 60 mm — 52 mm 121 mm — 45 mm 7 mm — 3.75 kg
91101604 SPZ160-04 160 mm 164 mm 2 2517 60 mm — 52 mm 131 mm — 45 mm 7 mm — 4.45 kg
91101804 SPZ180-04 180 mm 184 mm 2 2517 60 mm — 52 mm 151 mm — 45 mm 7 mm — 6.2 kg
91101904 SPZ190-04 190 mm 194 mm 3 2517 60 mm — 52 mm 161 mm 3.5 mm 45 mm 3.5 mm — 7.1 kg
91102004 SPZ200-04 200 mm 204 mm 6 2517 60 mm 8 mm 52 mm 171 mm 3.5 mm 45 mm 3.5 mm 124 mm 5.23 kg
91102244 SPZ224-04 224 mm 228 mm 5 2517 60 mm — 52 mm 195 mm 3.5 mm 45 mm 3.5 mm 124 mm 6.43 kg
91102504 SPZ250-04 250 mm 254 mm 5 2517 60 mm — 52 mm 221 mm 3.5 mm 45 mm 3.5 mm 124 mm 7.5 kg
91102804 SPZ280-04 280 mm 284 mm 5 2517 60 mm — 52 mm 251 mm 3.5 mm 45 mm 3.5 mm 124 mm 9.4 kg
91103154 SPZ315-04 315 mm 319 mm 5 2517 60 mm — 52 mm 286 mm 3.5 mm 45 mm 3.5 mm 124 mm 8.45 kg
91103554 SPZ355-04 355 mm 359 mm 5 2517 60 mm — 52 mm 326 mm 3.5 mm 45 mm 3.5 mm 124 mm 10.37 kg
91104004 SPZ400-04 400 mm 404 mm 5 2517 60 mm — 52 mm 371 mm 3.5 mm 45 mm 3.5 mm 124 mm 12.94 kg
91104504 SPZ450-04 450 mm 454 mm 5 3020 75 mm — 52 mm 421 mm 0.5 mm 51 mm 0.5 mm 146 mm 15.92 kg
91105004 SPZ500-04 500 mm 504 mm 5 3020 75 mm — 52 mm 471 mm 0.5 mm 51 mm 0.5 mm 146 mm 18.0 kg

Product Information

Material
Cast iron
