Chiaravalli V-Belt Pulley for Taper Bushes SPZ 5 Grooves — product photo
Chiaravalli

V-Belt Pulley for Taper Bushes SPZ 5 Grooves

Cast-iron SPZ V-belt pulley with 5 grooves, machined to take a Taper-Lock® bush (bush size and maximum bore per diameter in the table). Type is the hub form shown in the drawing.

Product Configuration

Select a row to add it to your quote

Code ModelPOTypeBushMax boreEFJKLMN Weight CAD
91100855 SPZ85-05 85 mm 89 mm 8 1610 42 mm — 64 mm 60 mm 39 mm 25 mm — — 1.0 kg
91100905 SPZ90-05 90 mm 94 mm 8 1610 42 mm — 64 mm 61 mm 39 mm 25 mm — — 1.29 kg
91100955 SPZ95-05 95 mm 99 mm 8 1610 42 mm — 64 mm 66 mm 39 mm 25 mm — — 1.45 kg
91101005 SPZ100-05 100 mm 104 mm 8 2012 50 mm — 64 mm 71 mm 32 mm 32 mm — — 1.4 kg
91101065 SPZ106-05 106 mm 110 mm 8 2012 50 mm — 64 mm 76 mm 32 mm 32 mm — — 1.72 kg
91101125 SPZ112-05 112 mm 116 mm 8 2012 50 mm — 64 mm 83 mm 32 mm 32 mm — — 1.9 kg
91101185 SPZ118-05 118 mm 122 mm 8 2012 50 mm — 64 mm 90 mm 32 mm 32 mm — — 2.2 kg
91101255 SPZ125-05 125 mm 129 mm 8 2012 50 mm — 64 mm 96 mm 32 mm 32 mm — — 2.63 kg
91101325 SPZ132-05 132 mm 136 mm 8 2517 60 mm — 64 mm 103 mm 19 mm 45 mm — — 2.75 kg
91101405 SPZ140-05 140 mm 144 mm 2 2517 60 mm — 64 mm 111 mm — 45 mm 19 mm — 3.34 kg
91101505 SPZ150-05 150 mm 154 mm 2 2517 60 mm — 64 mm 121 mm — 45 mm 19 mm — 4.15 kg
91101605 SPZ160-05 160 mm 164 mm 2 2517 60 mm — 64 mm 131 mm — 45 mm 19 mm — 4.93 kg
91101805 SPZ180-05 180 mm 184 mm 2 2517 60 mm — 64 mm 151 mm — 45 mm 19 mm — 6.72 kg
91102005 SPZ200-05 200 mm 204 mm 3 2517 60 mm — 64 mm 171 mm 9.5 mm 45 mm 9.5 mm — 8.63 kg
91102245 SPZ224-05 224 mm 228 mm 5 2517 60 mm — 64 mm 195 mm 9.5 mm 45 mm 9.5 mm 124 mm 7.59 kg
91102505 SPZ250-05 250 mm 254 mm 5 2517 60 mm — 64 mm 221 mm 9.5 mm 45 mm 9.5 mm 124 mm 8.3 kg
91102805 SPZ280-05 280 mm 284 mm 5 2517 60 mm — 64 mm 251 mm 9.5 mm 45 mm 9.5 mm 124 mm 9.0 kg
91103155 SPZ315-05 315 mm 319 mm 5 2517 60 mm — 64 mm 286 mm 9.5 mm 45 mm 9.5 mm 124 mm 10.14 kg
91103555 SPZ355-05 355 mm 359 mm 5 2517 60 mm — 64 mm 326 mm 9.5 mm 45 mm 9.5 mm 124 mm 11.96 kg
91104005 SPZ400-05 400 mm 404 mm 5 3020 75 mm — 64 mm 371 mm 6.5 mm 51 mm 6.5 mm 146 mm 14.5 kg
91104505 SPZ450-05 450 mm 454 mm 5 3020 75 mm — 64 mm 421 mm 6.5 mm 51 mm 6.5 mm 146 mm 17.55 kg
91105005 SPZ500-05 500 mm 504 mm 4 3030 75 mm — 64 mm 471 mm 6 mm 76 mm 6 mm 146 mm 21.15 kg

Product Information

Material
Cast iron
