Thenar 3-Lobe Knob with Threaded Pin — Part THP30
Thenar

3-Lobe Knob with Threaded Pin — Part THP30

Knobs and handles · 3-Lobe Knob (threaded pin)

Product Configuration

Select a row to add it to your quote

Code DLd1l2dl Weight
01THP30B10 30 mm 19 mm 17 mm 7 mm M5 10 mm 0.012 kg
01THP30B15 30 mm 19 mm 17 mm 7 mm M5 15 mm 0.015 kg
01THP30B20 30 mm 19 mm 17 mm 7 mm M5 20 mm 0.015 kg
01THP30B25 30 mm 19 mm 17 mm 7 mm M5 25 mm 0.015 kg
01THP30B30 30 mm 19 mm 17 mm 7 mm M5 30 mm 0.016 kg
01THP30B40 30 mm 19 mm 17 mm 7 mm M5 40 mm 0.016 kg
01THP30C10 30 mm 19 mm 17 mm 7 mm M6 10 mm 0.014 kg
01THP30C15 30 mm 19 mm 17 mm 7 mm M6 15 mm 0.015 kg
01THP30C20 30 mm 19 mm 17 mm 7 mm M6 20 mm 0.016 kg
01THP30C25 30 mm 19 mm 17 mm 7 mm M6 25 mm 0.018 kg
01THP30C30 30 mm 19 mm 17 mm 7 mm M6 30 mm 0.019 kg
01THP30C40 30 mm 19 mm 17 mm 7 mm M6 40 mm 0.019 kg
01THP30C50 30 mm 19 mm 17 mm 7 mm M6 50 mm 0.019 kg
01THP30D10 30 mm 19 mm 17 mm 7 mm M8 10 mm 0.019 kg
01THP30D15 30 mm 19 mm 17 mm 7 mm M8 15 mm 0.022 kg
01THP30D20 30 mm 19 mm 17 mm 7 mm M8 20 mm 0.023 kg
01THP30D25 30 mm 19 mm 17 mm 7 mm M8 25 mm 0.025 kg
01THP30D30 30 mm 19 mm 17 mm 7 mm M8 30 mm 0.026 kg
01THP30D35 30 mm 19 mm 17 mm 7 mm M8 35 mm 0.027 kg
01THP30D40 30 mm 19 mm 17 mm 7 mm M8 40 mm 0.033 kg
01THP30D50 30 mm 19 mm 17 mm 7 mm M8 50 mm 0.034 kg
01THP30D60 30 mm 19 mm 17 mm 7 mm M8 60 mm 0.035 kg
01THP30D70 30 mm 19 mm 17 mm 7 mm M8 70 mm 0.036 kg

Product Information

Material
Polyamide-based (PA) technopolymer. Resistant to organic and inorganic chemical substances such as oils, greases, fuels and solvents. Black with satin finish.
